The Control and Simulation of the Live Washing Robot Based on the 6-DOF Manipulator

Abstract:

Against the shortcomings of the live washing artificially, this paper puts forward a system about live washing robot, this system contains hydraulic system, video surveillance system, automatic regulatory system, communication system and motion control system. These subsystems can cooperate to complete live washing tasks. The operator commands manipulator and car from a cabin on the truck via a portable control box. In order to protect the operator, this system takes use of the wireless communication. This robotic system can finish the washing task perfectly instead of human. As for the inverse kinematic about the manipulator, this paper puts forward a new algorithm which is combined geometric method with algebraic method and confirms it’s correctness by simulation.

• Periodical: Advanced Materials Research (Volumes 1049-1050)
• Pages: 1013-1017
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1049-1050.1013
• Online since: October 2014
• Authors: Lin Tan*, Shou Yin Lu, Jian Xiang Li, Jin Long Zhao, Jian Li
• Keywords: 6-DOF Manipulator, Geometry, Inverse Kinematic, Live Washing

References

[1] Ye Jing-An. Design and Research on the optimization of cleaning device for high-voltage hot-line cleaning robot [D]. Shanghai: Shanghai Jiao Tong University, 2008. (In Chinese).

[2] Lei Hui-Leng. A charged water flush accident analysis[J]. Electric Safety Technology, 2009, 7: 015. (In Chinese).

[3] Wang yu, Hui Jian-Hui. Electric power equipment insulation cleaning technology and Practice[J]. Cleaning Technology , 2003, 2: 16-19. (In Chinese).

[4] Gu Hong-Jun. The technical requirement of living washing in Substation primary equipment [J]. Chinese high-tech enterprises, 2011(24): 108-109. (In Chinese).

[5] He Li, Zhao Chen. Path planning method based on the geometry[J]. Journal of Harbin institute of technology, 2005, 37(7): 947-949. (In Chinese).

[6] Lee C S G. Robot arm kinematics, dynamics, and control[J]. Computer, 1982, 15(12): 62-80.

DOI: 10.1109/mc.1982.1653917

[7] Xiong You-Lun. Foundation of robot technology [M]. Hua Zhong University Of Science And Technology Press, 1996. (In Chinese).

[8] Chen Peng, Liu Lu, Xu Fei. A Geometrical Method for Inverse kinematics of a kind of Humanoid Manipulator[J]2012. (In Chinese).

[9] Yahya S, Mohamed H A F, Moghavvemi M, et al. A new geometrical inverse kinematics method for planar hyper redundant manipulators[C]/Innovative Technologies in Intelligent Systems and Industrial Applications, 2009. CITISIA 2009. IEEE, 2009: 20-22.

DOI: 10.1109/citisia.2009.5224247

[10] Mohamed H, Yahya S, Moghavvemi M, et al. A new inverse kinematics method for three dimensional redundant manipulators[C]/ICCAS-SICE, 2009. IEEE, 2009: 1557-1562.

DOI: 10.1109/citisia.2009.5224247

[11] Wu J X, Qi X D, Wang Y, et al. ADAMS MATLAB Co-Simulation of Dynamics Parallel Manipulator[J]. Advanced Materials Research, 2011, 295: 2125-2128.

DOI: 10.4028/www.scientific.net/amr.295-297.2125

[12] Ángel L, Pérez M P, Díaz-Quintero C, et al. ADAMS/MATLAB Co-Simulation: Dynamic Systems Analysis and Control Tool[J]. Applied Mechanics and Materials, 2012, 232: 527-531.

DOI: 10.4028/www.scientific.net/amm.232.527

[13] Gao R Z, Xu Z Q, Zhang J J. Optimal Control of Semi-Active Suspension Based on ADAMS and MATLAB/ Simulink[J]. Applied Mechanics and Materials, 2011, 44: 1492-1495.

DOI: 10.4028/www.scientific.net/amm.44-47.1492
