Process Parameters Optimization for Plasma Spraying Nanostructured ZrO₂-7%Y₂O₃ Coating Based on Simulated Annealing Algorithm

Abstract:

Process parameters of nanostructured ZrO₂-7%Y₂O₃ coating during plasma spraying on the properties of the coating was optimized based on simulated annealing algorithm. BP neural network was applied to compute fitness of simulated annealing algorithm. A BP neural network model was built, four process parameters were input , the parameters included spraying distance, spraying electric current, primary gas pressure and secondary gas pressure, bonding strength of coating was output. Network was trained by orthogonal test data. Process parameters of coating were optimized by simulated annealing algorithm. The results show that maximal bonding strength of coating is 43.0377MPa. Process parameters for plasma spraying nanostructured ZrO₂-7%Y₂O₃ coating are spraying distance of 80mm, spraying electric current of 977.0283A, primary gas pressure of 0.3046MPa and secondary gas pressure 0.9886MPa.

• Periodical: Advanced Materials Research (Volume 1051)
• Pages: 12-16
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1051.12
• Online since: October 2014
• Authors: Bin Yang*
• Keywords: Nanostructured Coating, Neural Network, Plasma Spraying, Process Parameters Optimization, Simulated Annealing Algorithm

References

[1] Chris Berndt. Thermal spray processing of nanoscale materials[J]. Journal of Thermal Spray Technology, 2001，7(3): 147-181.

[2] Lbrahim A，Lima R S，Berndt C C，et al．Fatigue mechanical properties of nanostructured and conventional( TiO2) thermal spray coatings[J]． Surface and Technology，2007，201( 16 /17) : 7589-7596.

DOI: 10.1016/j.surfcoat.2007.02.025

[3] Lijie Weng, Yumei Bao, Saijia Lin. Bonding Strength of Plasma Sprayed HA /ZrO2 Composite Coating [J]. Light Industry Machinery，2010，28(4)：40-43.

[4] D. Goberman，Y. H. Sohn，L. Shaw，et al. Microstructure development of A12O3-13%TiO2 plasma sprayed coatings derived from nano crystalline powders[J]．Acta Material，2002 (50)：1141-1152.

DOI: 10.1016/s1359-6454(01)00414-1

[5] Dongsheng Wang，Zongjun Tian，Lida Shen，et al. Microstructure and formation mechanism of plasma-sprayed nanostructured composite ceramic coatings [J]. The Chinese Journal of Nonferrous Metals，2009，19(1)：77-83.

[6] Jiming Fan, Yuxiang Lu, Chunling Li, et al. Optimization of Plasma Spraying Process Parameters for Cr3C2-NiCr Coating [J]. Material & Heat Treatment, 2009, 38(20): 100-103.

[7] Jiang Zhengzheng, Wang Dandan, Chen Xiaohong, Li Yiming. Improved Simulated Annealing Algorithm for Multi-target Tracking[J]. Computer & Digital Engineering, 2013, 41(11): 1741-1743.

[8] Jie Hu, Fuwu Yan. A Research on the misfire diagnosis Method of gasoline engine based on BP neural network [J]. Automotive Engineering, 2011, 33(2): 101-105.

[9] Bin Yang, Wenjie Fan, Zida Zhang, et al. Identifying dynamic force of hydro-pneumatic suspension [J]. Transactions of the Chinese Society for Agricultural Machinery, 2007, 38(4): 16-18.

[10] Bin Yang, Haiyan Tang. Identification of dynamic load of air suspension system [J]. Transactions of the Chinese Society of Agricultural Engineering, 2010, 26(03): 130-134.

[11] Gou Yanni, Wang Yingmin, Wang Qi. Applying Simulated Annealing Algorithm toLocating Multistatic Bouy [J]. Journal of Northwestern Polytechnical University, 2013, 31(4): 607-613.

[12] Deng Wei, Lu Jiansha, Weng Yaowei. Scheduling vesearch of work-shop with bottleneck in cycle-time [J]. Journal of Mechanical & Electrical Engineering, 2013, 30(3): 373-379.
