Study on Friction Property of the Ni/ZrO₂ Composite Infiltrated Layer on Cast Steel Surface under Dry Fraction

Abstract:

The surface composite layer Ni/ZrO₂ on the ZG45 cast steel surface was fabricated through vacuum infiltration casting method. This paper researched on the Ni/ZrO₂ composite infiltrated layer morphology, hardness and the friction property under fry friction. The results show that the main phase structure of the layer is ZrO₂, Cr₂B, NiB and FeNi. The macrohardness of the layer is HRC60~64. The micohardness presents gradient change. The maximum hardness appears at subsuface. The 10% ZrO₂ composite infiltrated layer wear resistance increases 10 times and 15% ZrO₂ composite infiltrated layer increases 22.6 times than ZG45 under the 100N load. The 10% ZrO₂ composite infiltrated layer wear resistance increases 8.5 times and 15% ZrO₂ composite infiltrated layer increases 21.9 times under 250N load. The wear resistance has greatly improved.

• Periodical: Advanced Materials Research (Volume 1055)
• Pages: 73-77
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1055.73
• Online since: November 2014
• Authors: Xian Ming Sun, Gui Rong Yang, Lei Wei, Yu Lan Liu
• Keywords: Cast Steel, Dry Sliding Friction, Friction Property, Ni-Based Composite Infiltrated Layer

References

[1] X M Sun, G R Yang, W M Song, J Li, Y MA and Y Zhou: Wear Performance of Ni/ZrO2 Infiltrated Composite Layer, Journal of Wuhan University of Technology (Materials Science Edition), No. 1 (2012), pp.73-78.

DOI: 10.1007/s11595-012-0410-x

[2] G R Yang, Y Hao and W M Song: An investigation of the structure and properties of infiltrated layer on the surface of copper alloy, Materials Science and Engineering, Vol. 399(1-2) (2005), pp.206-215.

DOI: 10.1016/j.msea.2005.03.106

[3] X M Sun: Study on vacuum infiltration casting technique and tribological properties of Ni-based surface infiltrated layer on cast steel substrate, China Academy of Machinery Science & technology dissertation, (2011), pp.57-84.

[4] T P Xuan and D Min: Effect or rare earth on micstrusture of vacuum melting Ni-based self-fluxing alby coatings, Journal of Rare Earths, Vol. 22 No. 4(2004) pp.517-520.

[5] J Y Zhang, G R Yang, Y Ma and H Wang: Investigation on Wear Resistance of Ni-based Infiltrated Layer on Cast Steel Substrate, Hot Working Technology, Vol. 39 No. 3(2010) pp.62-65.
