Bursts Detection in Water Distribution Networks Based on Real-Time State Simulation

Abstract:

Based on the improved weighted-least-square model and fuzzy similarity ratio method, a methodology is proposed to detect pipe bursts in real-time. When SCADA data is obtained DFP algorithm is used to get the real network state. Then the real values of burst characteristics are computed. And the hypothetical values assuming each pipe as the accident pipe are calculated for comparison. The fuzzy similarity ratio method is used to judge whether there is a pipe burst. If there is, the hypothetical value that is most similar to the real value is the accidental state and the corresponding assumed break is the burst location. According to the methodology a software system is developed with Delphi 7 for verification. The running results of a designed network show that the methodology is reliable and its detection accuracy is over 45%.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 1692-1698
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.1692
• Online since: December 2014
• Authors: Hui Zhang*, Ting Lin Huang, Mei Hua Cao, Jin Lan Xu
• Keywords: Accident Warning, Burst Detection, State Simulation, Water Distribution Network

References

[1] Ziwei Zhao, Shuping Li, Yanchun Zhou, et al.: Water Purification Technology Vol. 33 (2014), p.11.

[2] Mingming Rao: An Algorithmic of Water Pipes Burst Detection based upon Probability (South China University of Technology, Guangzhou 2012).

[3] Weiping Cheng, Dandan Zhao, Gang Xu, et al.: Journal of Zhejiang University (Engineering Science) Vol. 47 (2013), p.1057.

[4] Dandan Zhao: Research of Burst Detection based on SCADA (Zhejiang University, Hangzhou 2014).

[5] Xiaofei Qing, Xinhua Zhao, Haiya Zhang, et al.: China Water & Wastewater Vol. 28 (2012), p.68.

[6] Pudar R S and Liggett J A: Journal of Hydraulic Engineering Vol. 118 (1992), p.1031.

[7] Zebin Sheng: Study on the Intellectual Analysis Technology of Leak Location in Water Supply Networks (Qingdao Techonological University, Qingdao 2012).

[8] Jinghu: Experimental Study on Leak Detection of the Water Distribution Network based on Hydraulic Transient Theory (Harbin Institute of Technology, Harbin 2010).

[9] Di Wu, Fang He and Jianmin Lin: Water & Wastewater Vol. 38 (2012), p.448.

[10] Qie Zhihong: Study on Optimal Locating of Pressure Monitoring Station and Model of Locating of Bursting Point in Urban Water Supply System (Agriculture University of Hebei, Shijiazhuang 2009).

[11] Liu Jun and Yu Guoping: Journal of Tongji University (natural science) Vol. 39 (2011), p.401.

[12] Cong Haibing and Huang Tinglin: Journal of Xi'an University of Architecture & Technology (Natural Science Edition) Vol. 35 (2003), p.343.

[13] Shen Rongfang: Operational Research (China Machine Press, Beijing 2005).

[14] Hui Zhang, Tinglin Huang and Wenjie He: Journal of Central South University of Technology Vol. s1 (2009), p.51.

[15] Huang Tinglin, Cao Meihua. and Zhang Hui: Water & Wastewater Vol. 33 (2007), p.104.

[16] Cao Meihua: Detection of Pipe Leakage and Bursts Based on the SCADA System of Water Supply Networks (Xi'an University of Architecture & Technology, Xi'an 2007).
