Study on Effect of Frame Structures Crossed by Shallow-Buried and Mining Tunnelling

Abstract:

During the shallow-buried tunnel excavation, the formation will be affected and the nearby buildings will be caused fracture. By using three dimensional software MIDAS/GTS, the interactions among structures-soil-tunnel system is considered in this paper, and the working condition of shallow-buried underground excavation is simulated in the independent foundation of frame structures. It is indicated that building will tilt to the side of tunnel as the horizontal distance L between building and tunnels is increasing, after reaching certain distance, the influence to the building tends to little, at the same time, the maximum first principal stress P₁ and maximum deformation rate E₁ show a trend of decrease. When the kind of soil is worse, the settlement and non-uniform settlement of buildings increase, meanwhile P₁ and E₁ increase. With the increasing story of the framework, the settlement of building is nearly not affected, and P₁ and E₁ decrease slightly.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 341-346
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.341
• Online since: December 2014
• Authors: Gang Wei*, Hao Qiang Yu
• Keywords: Finite Element Method (FEM), Independent Foundation, Shallow-Buried Tunnels, Structure

References

[1] HUANG Zhengjia. Monitoring and analysis of the shallow mining excavation of a metro tunnel embedded in soft water-soaking ground. Modern Tunnelling Technology, 2010, 47(3): 81－86. (in Chinese).

[2] SONG Jian, FAN Yunyun, HUO Yanpeng. Ground surface settlement law of a shallow-depth subway station under complex conditions. Modern Tunnelling Technology, 2012, 49(6): 88－92, 138. (in Chinese).

[3] ZHANG Dingli, LI Pengfei, HOU Yanjuan, et al. Influence due to urban tunnel excavation on ground buildings and its countermeasures. Chinese Journal of Geotechnical Engineering, 2010, 32(2): 296－302. (in Chinese).

[4] Chungsik Y, Jae-Hoon K. A web-based tunneling-induced building/utility damage assessment system: TURISK. Tunnelling and Underground Space Technology, 2003, 18(5): 497－511.

DOI: 10.1016/s0886-7798(03)00067-1

[5] SUN Yukun, GUAN Fuling. Shield tunnel construction induced influence on the settlement of masonry buildings. China Railway Science, 2012, 33(4): 38－44. (in Chinese).

[6] PENG Chang, JI Yulin, LUO Hanbin, et al. Numerical simulation of effects of double-tube parallel shield tunneling on neighboring building. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(Supp. 2): 3868-3874. (in Chinese).

[7] WEI Gang, WEI Xinjiang. Effect analysis of frame building crossed by double-line parallel shield tunnel. Chinese Journal of Underground Space and Engineering, 2013, 9(2)：339－343. (in Chinese).

[8] WEI Gang, HU Huihui, ZHANG Shimin. Study on the influence of construction of shallow-buried underground excavation tunnel on adjacent framework buildings. Disaster Advances, 2013, 6(S4): 149－156.

[9] China Academy of Building Research. GB50007-2011 Code for design of building foundation. Beijing: China Building Industry Press, 2011. (in Chinese).

[10] The Ministry of Construction of the People's Republic of China. GB50010-2010 code for design of concrete structures. Beijing: China Building Industry Press, 2010. (in Chinese).
