SOM-SEM-EDS Identification of Tool Wear Mechanisms in the Dry-Machining of Aerospace Titanium Alloys

Abstract:

Titanium based alloys, mainly UNS R56400 (Ti6Al4V), are increasingly being applied in the airship building industry due to its excellent physicochemical properties. Machining operations are usually required in the manufacturing processes of Ti based aerospace structural elements. However, high reactivity of Ti provokes a quick tool wear. So, in order to reach an economically acceptable production level, it is necessary to minimize the costs associated to tool wear. In this work, Scanning Electron Microscopy (SEM), Stereoscopic Optical Microscopy (SOM) and Energy Dispersive Spectroscopy (EDS) have been used for both analysing and identifying secondary adhesion mechanisms that are taking place when an aeronautical titanium alloy is machined. Special severe cutting conditions have been applied. Thus, titanium alloy have been dry machined with TiN coated WC-Co tools. Results obtained have shown that tool wear is controlled by a secondary adhesion mechanism, which presents two stages. A first stage is constituted by a TiOx multi-film formed onto the tool surfaces. A second step involves the mechanical adhesion of the alloy material to those surfaces. When this material is removed, tool particles are dragged off causing tool wear.

• Periodical: Advanced Materials Research (Volume 107)
• Pages: 77-82
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.107.77
• Online since: April 2010
• Authors: Miguel Álvarez, Álvaro Gómez-Parra, J. Salguero, Moises Batista, Milagros M. Huerta, Mariano Marcos Bárcena
• Keywords: Dry Machining, SOM-SEM-EDS, Sustainable Manufacturing, Ti6Al4V, Tool Wear

References

[1] Hinrichsen, J., Bautista, C., Air & Space Europe, 3(3-4) (2001) 119-124.

[2] Álvarez, M., González, J.M., Carrilero, M.S., Villanueva, J.A., Sánchez, J.M., Marcos, M., An. Ing. Mec., 15 (2004) 2825-2830.

[3] Álvarez, M., Carrilero, M.S., Torres, F., Grille, B., Barro, M., Marcos, M., Actas del XIV Congreso de Máquinas-Herramienta y Tecnologías de Fabricación, Vol 2 (2002) 725-74.

[4] J.L. Cantero, J.M. Sánchez-Sola, M. M Tardio, M.A. Sebastián, M.S. Carrilero, M. Marcos, M.H. Miguélez, Rev. Metal. Madrid, (2005) pp.355-360.

[5] J.L. Cantero, M. M Tardio, J.A. Canteli, M. Marcos, M.H. Miguélez, International Journal of Machine Tools & Manufacture 45, (2005), 1246-1255.

DOI: 10.1016/j.ijmachtools.2005.01.010

[6] Bentley, S.A., Goh, N., Aspinwall, D., Journal of Materials Processing Technology 118 (2001) 21-28.

[7] ASM Handbook. Vol. 2: Properties and selection: Nonferreous alloys and special-purpose materials, ASM International (Ohio, USA), (1995).

[8] L.N. López de Lacalle, A. Lamikiz, J. A. Sánchez, Mecanizado de Alto Rendimiento, Procesos de arranque, Ediciones técnicas Izaro (Bilbao, España), 2. 004.

[9] M. Marcos, M.A. Sebastián-Pérez, J.P. Contreras-Samper, M. Sánchez-Carrilero, M. SánchezLópez and J.M. Sánchez-Sola, Journal of Materials Procesing Technology, 162-163 (2005) pp.644-648.

DOI: 10.1016/j.jmatprotec.2005.02.061

[10] E.M. Rubio, A.M. Camacho, J.M. Sánchez-Sola and M. Marcos, Journal of Achievements in Materials and Manufacturing Engineering, 16 (2005) pp.164-170.

[11] J. Gerez, M.S. Carrilero, J. Salguero, M. Batista, M. Marcos, Proc. 3rd Manufacturing Engineering Society International Conference, MESIC 2009, Alcoy (SPAIN) (2009).
