Wind Turbine Planetary Gearbox Fault Analysis Based on Bispectrum

Abstract:

Through researching the fault vibration signal characteristics of planetary gearbox, various forms of quadratic phase coupling phenomenon were found in the signals. Bispectrum has properties such as detecting the quadratic coupling phenomena and restraining gaussian noise signal, and it can be well used in the planetary gearbox fault diagnosis. Meanwhile, the sun gear distributed fault (gear wear) and partial fault (root crack, partial broken teeth) are simulated in the wind turbine test bench built in the laboratory. By analyzing the structure characteristics of its frequency through bispectrum, the fault of the gear is effectively diagnosed.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 1861-1868
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.1861
• Online since: December 2014
• Authors: Yong Xin Feng, Wei Peng Zhang*, Tao Yang, Xiao Wen Deng, Shi Liu
• Keywords: Bispectrum, Fault Feature Extraction, Planetary Gearbox, Quadratic Phase Coupling, Sun Gear, Wind Turbine

References

[1] CHEN Xuefeng. Research and application of condition monitoring and fault diagnosis technology in wind turbines[J]. Journal of mechanical engineering, 2011, 47(9): 46-50.

[2] BARSZCZ T, ROBERT B. Application of spectral kurtosis for detection of a tooth crack in the planetary gear of a wind turbine[J]. Mechanical Systems and Signal Processing，2009(23)：1352-1365.

DOI: 10.1016/j.ymssp.2008.07.019

[3] INALPOLAT M, KAHRAMAN A. A theoretical and experimental investigation of modulation sidebands of planetary gear sets[J]. Journal of Sound and Vibration，2009，323：677-696.

DOI: 10.1016/j.jsv.2009.01.004

[4] Williams W J, Zalubas E J．Helicopter transmission fault detection via time-frequency , scale and spectral methods[J]．Mechanical Systems and Signal Processing，2000，14(4)：545-559.

DOI: 10.1006/mssp.2000.1296

[5] FENG Zhipeng, CHU Fulei. Vibration spectral characteristics of distributed gear fault of planetary gearboxes[J]. Proceedings of the CSEE, 2013, 33(2): 118-125.

[6] FENG Zhipeng, ZHAO Leilei, CHU Fulei. Vibration spectral characteristics of localized gear fault of planetary gearboxes[J]. Proceedings of the CSEE, 2013, 33(5): 119-127.

[7] FENG Zhipeng, ZHAO Leilei, CHU Fulei. Amplitude demodulation analysis for fault diagnosis of planetary gearboxes[J]. Proceedings of the CSEE, 2013, 33(8): 107-110.

[8] FENG Zhipeng, CHU Fulei. Frequency demodulation method for fault diagnosis of planetary gearboxes[J]. Proceedings of the CSEE, 2013, 33(11): 112-117.

[9] HUANG Qian，JIANG Dongxiang, HONG Liangyou, et al. Application of wavelet neural networks on vibration fault diagnosis for wind turbine gearbox[J]. Lecture Notes in Computer Science，2008，5264：313-320.

DOI: 10.1007/978-3-540-87734-9_36

[10] ZHANG Xianda. Modern signal processing (Second Edition)(M). Beijing. Tsinghua University Press, (2002).
