Doubly Fed of Induction Generators Wind Turbine Frequency Control Based on Power Curve of Inertia Control and Pitch Angle Control

Abstract:

With many grid-connected wind farms of Doubly-fed Induction Generator (DFIG) type taking the palce of conventional synchronous generators, the frequency control ability of the system will decrease. But the existing control strategy based on maximum wind power tracking of DFIG can not response to the deviation of the system frequency. This paper proposes a new hybrid frequency control strategy based on the research of the frequency response to the doubly fed induction wind turbine curves switching inertia control loop and the ability for the pitch angle control participating in the system primary frequency modulation. The strategy reduces the initial rate of change and the steady state error of system frequency with the combined action of the curves switching inertial control and pitch frequency control. Finally, the simulation results of the two areas with four generators validate the effectiveness of the strategy.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 228-232
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.228
• Online since: December 2014
• Authors: Xiao Ying Zhang, Si Wen Li*
• Keywords: Doubly Fed Induction Generator (DFIG), Frequency Regulation, Inertia Control, Pitch Angle Control, Switching Power Curve

References

[1] Han Minxiao, Cui Junli, Yao Shujun, et al. Frenquency control characteristics for a power system with large amounts of wind power[J]. Aotomation of Electric Power Systems, 2008, 32( 1) : 29-33．(in Chinese).

[2] Ekanayake J, Jenkins N. Comparison of response of doubly fed and fixed-speed induction generator wind turbines to changes in network frequency[J]. IEEE Trans on Energy Conversion, 2004, 19 (4): 1496-1503.

DOI: 10.1109/tec.2004.827712

[3] Sun Chunshun, Wang Yaonan, Li Xinran. Synthesized power and frequency control of wind power generation system assisted through flywheels[J]. IEE Proceedings of the CSEE, 2008, 28(29): 111-116(in Chinese).

[4] Anaya-Lara O, Hughes F M, Jenkins N, et al. Contribution of DFIG-based wind farms to power system short-term frequency regulation[J] . IEEE Proceedings: Generation Transmission and Distribution, 2006, 153(2): 164-170.

DOI: 10.1049/ip-gtd:20050264

[5] P. Kundur, Power system stability and control[M]. New York: McGraw-Hill. (1993).
