Effect of Wind Power Integration on the Self-Excitation Risks in Weak Interconnection Power Grid

Abstract:

To explore the self-excitation risks in weak interconnection power grid from the wind power flow, a vector control model of variable speed wind turbine based on doubly fed induction generator (DFIG) is established using electromagnetic transient simulation software PSCAD/ EMTDC. Start from the basic circuit model, the self-excitation phenomenon is analyzed with wind power integration. Simulation results show that the effect of wind power integration on the self-excitation risk is mainly determined by DFIG’s operation method, and wind power integration will affect self-excitation engineering judgment method at the same time. When DFIG works in phase late operation or has no reactive power exchange with the main power grid, cutting the wind turbine after broken thread quickly can restrain the worsening trend to a certain extent. However cutting the wind turbine after broken thread when DFIG works in phase advance operation may cause a voltage jump of the hydraulic synchronous generator in parallel with the wind turbine.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 909-914
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.909
• Online since: December 2014
• Authors: Yi Lei Mei*, Yu Fei Teng, Rui Xing Lin, Bo Zhou, Li Jie Ding, Hua Zhang
• Keywords: DFIG, PSCAD/EMTDC, Self-Excitation, Weak Interconnection Power Grid

References

[1] H. Zhang, M. Li, L. J. Ding. Study on Self-excitation Judgment Method for Small Hydro Generator in Local Grid, Power System Protection and Control, vol. 41, no. 20, pp.112-117, (2013).

[2] X. Q. Zhang, J. T. Kang, L. Li et al. Survey on the Research of Power System Self-excitation, Journal of Electric Power, vol. 25, no. 4, pp.311-314, (2010).

[3] J. L. He, J. H. He, X. L. Wang, et al. Cause of Generator Self-excitation and Its Influences on Operation of UHV Transmission Lines, Automation of Electric Power Systems, vol. 35, no. 23, pp.52-58, (2011).

[4] M. J. Chen, J. G. Chen, M. Ding. Judging Self-excitation in Multi-machine System by State-space Method , Power System Technology, vol. 28, no. 15, pp.53-56, (2004).

[5] F. S. Liu, R. H. Jiang. Synchronous Motor Self-excitation Vector analysis. Proceedings of the CSEE, vol. 7, no. 6, pp.63-73, (1987).

[6] W. J. Cui, C. Lu, Z. H. Xia, et al. Simulation of Self-excitation of Generators Connected to Long Transmission Lines, Tsinghua Univ: Sci & Tech, vol. 42, no. 9, pp.1154-1157, (2002).

[7] Burton T, Jenkins N, Sharpe D, et al. Wind Energy Handbook. Wiley, (2011).

[8] GWEC. Global Wind Report 2012[M/OL]. [2013, 4, 15]. http: /www. gwec. net/wp-content/uploads/2012/06/Annual_report_2012_LowRes. pdf.

[9] S. L. Feng, H. X. Zhao, P. C. Ren, W. S. Wang, H. Z. Dai. PSCAD/EMTDC Based Simulation Study on Dynamic Model of Double-Fed Variable Speed Wind Turbine[J], Power System Technology, vol. 31, no. 17, pp.30-35, (2007).

[10] Y. K. He, J. B. Hu, L. Xu. Operation and Control of Double-fed Induction Generator Systems for wind turbines. Beijing: China Electric Power Press, (2011).

[11] Y. Huang, Y. H. Zhang, Y. Min, et al. Security and Stability Characteristics and Control Strategies for Isolated Hydro Power Groups. Automation of Electric Power Systems, vol. 36, no. 9, pp.1-5, (2012).
