Acousto-Optic Double Control Automatic Alarm and Lighting Circuit Design

Abstract:

In this paper, the design and construction of the acousto-optic double control automatic alarm and lighting circuit. Through analyzing the existing solutions, using an infrared tube, electret sensor as well as the main device, by 555 multivibrator principle of design and production. This system sound control circuit, control circuit and the infrared light control circuit, and the door alarm circuit, and has the function of alarm lighting using infrared good concealment, the alarm can be used in day and night, at the same time controlling light lamp has the effect of energy saving.

• Periodical: Advanced Materials Research (Volumes 1079-1080)
• Pages: 1053-1056
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1079-1080.1053
• Online since: December 2014
• Authors: Zhi Jun Zhang*
• Keywords: Call the Police, Electret Sensor, Infrared Tube, Lighting, Photosensitivetransistor

References

[1] Hong Men. Electronic components [M]. Beijing: People's posts and telecommunications press, 2008: 118.

[2] Dejie Song. Intelligent energy-saving controller [J]. Journal of electronic production, 2008-18.

[3] Rugui Xiong. Shade type infrared [J]. Journal of sound and light alarm device electronic production, 2009, (9): 97.

[4] Lisong Zhao. 555 time base circuit principle design and application [M]. Beijing: Electronic industry press, 2007: 146.

[5] Peixiang Tan. 555 time base circuit knowledge charts [M]. Beijing: Electronic industry press, 2007: 113.

[6] Zhifu Sun. Electric energy-saving small night light type high brightness [J]. Journal of Radio, 2008: 23.
