Finite Element Analysis of Corrosion Damaged Pipeline Using PZT-Based Ultrasonic Guided Wave Energy Method

Abstract:

PZT-based ultrasonic guided wave has played an important role in health monitoring of pipeline structures. By using the PZT-based ultrasonic guided wave energy method and finite element software ABAQUS, the numerical simulation is performed to analyze various corrosion damaged pipeline structures, emphasizing on the damage identification, sensitivity analysis and longitudinal energy attenuation of the guided wave along various corrosion damaged pipelines. The preliminary analysis of the echo signals shows that the grass-like clutter wave belongs to echoes of the corrosion damage of the pipeline, and the wave energy spreads faster here. At the same time, by frequency spectrum analysis of the echo signal, the relationship between the reflection coefficient and the radial depth of defection is made which can be used to approximately evaluate geometrical dimension of the damage.

• Periodical: Advanced Materials Research (Volumes 1079-1080)
• Pages: 368-373
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1079-1080.368
• Online since: December 2014
• Authors: Shi Yan, Xin Zi Yuan, Nai Zhi Zhao, Wei Wang, Yang Cheng
• Keywords: Corrosion Damage, Energy Density, Numerical Simulation, Pipeline Damage Detection, Reflection Coefficient, Ultrasonic Guided Wave

References

[1] Northeast Oil Movement Bureau, Institute of Metal Research of Chinese Academy of science: Assessment method for corrosion of oil and gas transmission steel pipeline SY/T6151-1995(China National Petroleum Corporation, Beijing1995).

[2] D.A. Ta: Technical AcousticsVol. 20(3)2001, p.131.

[3] Z.G. Zhou: NDT Vol. 28(2)2006, p.57.

[4] S. Yan, W. Sun, G. Song, H.C. Gu, L.S. Huo, B. Liu and Y.G. Zhang: Smart Materials and Structures Vol. 18(4)2009, p.1.

[5] ZHAO Xiaoyan, LI Hongnan. Crack monitoring of concrete beam based on piezoelectric sensor[J]. Piezoelectrics&Acoustooptics, 2009, 31(3): 433-437.

[6] YAN Shi, SUN Wei. Erical simulation for concrete structure health monitoring based on smart piezoelectric transducer array [J]. Advances in Science and Technology, 2008, 56: 469-476.

[7] Shi Yan, Ji Qi, Naizhi Zhao, Yang Cheng, Sheng-Wenjun Qi《Multiple Crack Detection of Pipes Using PZT-based Guided Waves》, Applied Mechanics and Materials.

DOI: 10.4028/www.scientific.net/amm.448-453.3702

[8] Shi Yan, Ji Qi, Naizhi Zhao, Haoyan Ma, Hui Wang《Defect Detection in Pipelines Using Time Reversal of PZT-based Guided Waves》, Proceedings of the Twenty-third (2013) International Offshore and Polar Engineering.

[9] Z.Q. Liu and X. Liu: NDT Vol. 22(9)2000, p.403.

[10] H. Yang and C. Wang: Journal of North University of China (Natural Science Edition) Vol. 27(4)2006, p.348. (in Chinese).

[11] D.A. Ta, Z.Q. Liu and P.F. He: Chinese Journal of Applied Mechanics Vol. 20(2)2003, p.72. (in Chinese).

[12] Rose J L. Recent advances in guided wave NDE [ J] . 1995 IEEE Ultrasonics Symp. 1995: 761~ 770.
