EMI-Based Damage Identification for Beam Structures

Abstract:

A damage identification method is proposed to identify the damage style and the damage parameters. By driving a pair of PZT patches out phase and in phase, the electric admittance of the PZT is obtained. The damage parameters are then identified from the changes of the admittance spectra caused by the appearance of damage. By comparing the identification result, the damage style can be determined and the damage parameters can be obtained. The middle basic particle swarm optimization algorithm is employed as a global search technique to back-calculate the damage. Experiments are carried out on beams. The results demonstrate that the proposed method is able to identify the damage style, and can effectively and reliably locate and quantify the damage in the beam.

• Periodical: Advanced Materials Research (Volume 1081)
• Pages: 358-362
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1081.358
• Online since: December 2014
• Authors: Yu Xiang Zhang*, Jian Hai Yang, Fu Hou Xu, Jia Zhao Chen
• Keywords: Damage Identification, Damage Stylers, Electromechanical Impedance, Swarm Optimization Algorithm

References

[1] G. Park, H. Sohn, C. R. Farrar, and D. J. Inman 2003 Overview of piezoelectric impedance-based health monitoring and path forward The Shock and Vibration Digest 35 451–463.

DOI: 10.1177/05831024030356001

[2] V. Giurgiutiu, A. Reynolds, and C. A. Rogers 1999 Experimental investigation of E/M impedance health monitoring for spot welded structural joints Journal of Intelligent Material Systems and Structures 10 802–812.

DOI: 10.1106/n0j5-6uj2-w1gv-q8mc

[3] G. Park, A. C. Rutherford, H. Sohn, and C. R. Farrar 2005 An outlier analysis framework for impedance-based structural health monitoring Journal of Sound and Vibration 286 229–250.

DOI: 10.1016/j.jsv.2004.10.013

[4] J. W. Ayres, F. Lalande, Z. Chaudhry, and C. A. Rogers 1998 Qualitative impedance-based health monitoring of civil infrastructures Smart Materials and Structures 7 599–605.

DOI: 10.1088/0964-1726/7/5/004

[5] G. Park, H. H. Cudney, and D. J. Inman 2001 Feasibility of using impedance-based damage assessment for pipeline structures Earthquake Engineering and Structural Dynamics 30 1463–1474.

DOI: 10.1002/eqe.72

[6] V. Giurgiutiu and A. Zagrai 2005 Damage detection in thin plates and aerospace structures with the electro-mechanical impedance method Structural Health Monitoring 4 99–118.

DOI: 10.1177/1475921705049752

[7] K. J. Xing and C. -P. Fritzen 2007 Monitoring of growing fatigue damage using the E/M impedance method Key Engineering Materials 347 153–158.

DOI: 10.4028/www.scientific.net/kem.347.153

[8] S. W. Shin and T. K. Oh 2009 Application of electro-mechanical impedance sensing technique for online monitoring of strength development in concrete using smart PZT patches Construction and Building Materials 23 1185–1188.

DOI: 10.1016/j.conbuildmat.2008.02.017

[9] J. D. R. V. De Moura Jr. and V. Steffen Jr. 2006 Impedance-based health monitoring for aeronautic structures using statistical meta-modeling Journal of Intelligent Material Systems and Structures 17 1023–1036.

DOI: 10.1177/1045389x06063087

[10] V Jr Lopes, G Park, H H Cudney, et al. 2000 Impedance based structural health monitoring with artificial neural network. Journal of Intelligent Material Systems and Structures 11 206-214.

DOI: 10.1106/h0ev-7pwm-qyhw-e7vf

[11] J. F. Xu, Y. Yang, C. K. Soh. 2004 Electromechanical impedance-based structural health monitoring with evolutionary programming Journal of Aerospace Engineering 17 182–193.

DOI: 10.1061/(asce)0893-1321(2004)17:4(182)

[12] Seunghee Park, Daniel J. Inman, Jong-Jae Lee, Chung-Bang Yun. 2008 Piezoelectric Sensor-Based Health Monitoring of Railroad Tracks Using a Two-Step Support Vector Machine Classifier Journal of Infrastructure Systems, 1480-88.

DOI: 10.1061/(asce)1076-0342(2008)14:1(80)

[13] Xi Maolong, Sun Jun, Xu Wenbo. 2008 An improved quantum-behaved particle swarm optimization algorithm with weighted mean best position Applied Mathmatics and Computation 205 751-759.

DOI: 10.1016/j.amc.2008.05.135

[14] W. Yan, C. W. Lim, J. B. Cai, W. Q. Chen. 2007 An electromechanical impedance approach for quantitative damage detection in Timoshenko beams with piezoelectric patches Smart Materials and Structures 16 1390–1400.

DOI: 10.1088/0964-1726/16/4/054
