Non-Linear Finite Element Analysis on Rubber O-Sealing Ring of SRM

Abstract:

ABAQUS was utilized to establish a three-dimensional simplified model for rubber O-sealing ring and simulate the mechanical state and deformation in working condition. The influence of medium pressures and compression ratios on the mechanical state were analyzed. The results show that both the maximum Von Mises stress and contact pressure of rubber ring increase as the medium pressure or compression ratio increases, so, larger compression ratio, without causing residual deformation, should be chosen. Based on the failure mode of SRM sealing structure, the failure criteria of the maximum contact stress and shear stress of rubber O-sealing ring were studied.
