Elastic-Plastic Constraints Analysis for Hole-Edge Crack

Abstract:

This paper mainly conducts an elastic-plastic constraint analysis on rectangular plate specimens with hole-edge crack under remote uniaxial uniformly distributed load by using J-A₂ elastic-plastic fracture theory. In order to analyze the effect of orifice on elastoplastic stress field of hole-edge crack tip, this paper calculates a series of round hole-edge crack, diamond hole-edge crack and corresponding pure crack models. The interference effects of the orifice shape on elastic-plastic J integral and crack constraint parameter A₂ are discussed. The results show that: the orifice has an amplification effect on the fracture driving force (J-integral), and this amplification effect in elastic-plastic is smaller than that in elastic; the orifice has a shielding effect on the crack tip constraint (A₂ parameter), and this shielding effect gradually weaken with the crack increasing.

• Periodical: Advanced Materials Research (Volume 1095)
• Pages: 505-509
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1095.505
• Online since: March 2015
• Authors: Yi Qin Xie*, Zhong Xian Wang, Yan Qing Zhang
• Keywords: Constraint, Diamond Hole, Elastic-Plastic J-Integral, Hole-Edge Crack, Round Hole, Uniaxial Load

References

[1] Newman J.C. Jr. An improved method of collocation for the stress analysis of cracked plates with various shaped boundaries, NASA TN, D-6376, 1971, 1-45.

[2] Bowie O. L. Analysis of an infinite plate containing radial cracks originating at the boundary of an internal circular hole[J]. J. Math. Phys. 1956, 35: 60-71.

DOI: 10.1002/sapm195635160

[3] Murakami Y. A. method of stress intensity factor calculation for the crack emanating from an arbitrarily shaped hole or the crack in the vicinity of an arbitrarily shape hole[J]. Trans. Japan Soc. Mech. Engrs, 1978, 44(378): 423-432.

DOI: 10.1299/kikai1938.44.423

[4] Hasebe N., Ueda M. Crack orinating from a corner of a square hole[J]. Eng. Frac. Mech. 1980, 13: 913-923.

DOI: 10.1016/0013-7944(80)90021-1

[5] Neel D. Stress intensity factors for cracks emanating from rectangular cutouts[J]. Int. J. Frac., 1970, 6: 393-400.

DOI: 10.1007/bf00182627

[6] Akihide Saimoto, Masaki Fujikawa. Stress intensity factors for cracks initiated from a center-holed plate with unsymmetrical lengths under tension[J]. Engineering Fracture Analysis. 2010, 17: 838-847.

DOI: 10.1016/j.engfailanal.2009.10.017

[7] Murakami Y. Stress intensity factors handbook[M]. Pergamon Press, World Publishing Corporation, (1987).

[8] Liu Bao Liang. Study for a cavity crack problem in linear elastic body [D]. Harbin: Harbin Institute of Technology. 2010, 6.

[9] Chao Y. J., Zhang L. Tables of plane strain crack tip fields: HRR and higher order terms, Me-Report, 97-1[R], Department of Mechanical Engineering, University of South Carolina, (1997).

[10] Wang Z. X., Huang Jian-Ye, Chao Y. J. and Lam P. S. Crack tip constraint under Biaxial loading in elastic-plastic materials[M]. American Society of Mechanical Engineers, Pressure Vessels and Pivision(Publication) PVP, 2010, 6: 179-188.

DOI: 10.1115/pvp2010-25854
