Research and Implementation of the Automatic Detection System of Aggregate Particles Characteristic Parameters Based on VC

Abstract:

For the purpose of obtaining the characteristic parameters of the asphalt mixture aggregate particles, a viable method using two-dimensional image was put forward in this paper. The automatic detection system of asphalt mixture aggregate characteristic parameters is developed based on VC++. A series of processing are done on the collected aggregate images, including image edge detection, image segmentation, morphological processing, region-labeling, contouring and so on .The region-labeling algorithm is improved ending with low complexity, high robustness. Database technology is used to deal with the storage, query of the results and several other operations. The whole system is characterized with perfect function, user-friendly interface and stable performance, which provides a practical and accurate method for the characteristic detection of asphalt mixture aggregate particles.

• Periodical: Advanced Materials Research (Volume 1096)
• Pages: 16-21
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1096.16
• Online since: April 2015
• Authors: Xue Li Hao*, Zhao Yun Sun, Wei Li, Yan Ju Hu
• Keywords: Aggregate Particles Detection, Characteristic Parameters, Contour Tracking, Database, Image Segmentation, Region-Labeling

References

[1] D. Penumadu, Strain Localization in Solid Cylindrical Clay Specimens Using Digital Image Analysis Technique, J. Soils and Foundations. 47(1) (2007) 67-78.

DOI: 10.3208/sandf.47.67

[2] X.N. Zhang, Designing asphalt mixture, J. Harbin University of C. E. & Architecture. 35 (1)(2002) 108-111.

[3] H.L. Zhang, Z.Y. Sun, Study on Asphalt Mixture Automatic Measurement and Interface Technology, J. onstruction Machinery & Construction Technology, 26 (4)(2009) 42-45.

[4] Z.Y. Sun, A.M. Sha, Q.L. Yao. Research on the Automatic Measurement System of the Asphalt Mixture, J. Chinese Journal of Scientific Instrument. 27 (4)(2006) 353-357.

[5] Y.J. Zhang, Image Engineering (Volume one) image processing (2nd edition), M. Beijing: Tsinghua University Press(2006).

[6] J. Shi, F.J. Zhang, B.F. Hao. Image segmentation algorithms based on wavelet transform and mathematical morphology,J. Technology journal of Taiyuan University. 40 (5)(2009) 490-493.

[7] W.J. Tong, J. Zhang, Target detection algorithm based on edge detection and the traditional difference method, J. 21 (2)(2011)37-40.

[8] H.J. Tao, J. Liu, J.W. Tian. Edge detection for remote sensing image based on wavelet transform and mathematical morphology, J. Infrared and laser engineering. 31(2)(2002) 154-157.

[9] B.S. Chen. A binary image connected component labeling method, J. Computer Engineering and Application(2006).

[10] Z.C. Dai. Actual combat training on Chinese version of SQL Server database programming.M. Beijing: People's Posts and Telecommunications Press(2004).
