Influence of Liner Material on Formation of Multiple Explosively Formed Projectiles Warhead Parameters

Abstract:

The law of influenced material of liner is researched by numerical simulation.Multiple explosively formed projectiles (MEFP) forming process is numerically simulated with different liner material,such as copper, aluminum, iron and so on.The law that the formation parameters of MEFP such as velocity, length-diameter ratio and radial dispersion angle,influenced by the density and ductility of liner material is educed.It reaches the conclusion that the velocity and radial dispersion angle of projectiles decreases 58% and 56% with the increasing density of the liner material; the length-diameter ratio of central projectile increases276%with the increasing ductility of the liner material, so in order to acquire good formation of MEFP parameters, the appropriate density and higher ductility should be chosen.

• Periodical: Advanced Materials Research (Volume 1096)
• Pages: 37-41
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1096.37
• Online since: April 2015
• Authors: Chang Xiao Zhao*, Fang Qian, Huai Zhi Zhang, Chong Ji, Yong Lv, Quan Min Xie
• Keywords: Explosively Formed Projectile, Liner, Mechanics of Explosion, Numerical Simulation

References

[1] Fong R, Ng W, Tang S and Thompson L．Multiple explosively formed penetrator (MEFP) warhead technology for mine and improvised explosive device (IED) neutralization [A]. Proceedings of the 22th International Symposium on Ballistics[C]. Vancouver, BC Canada: International Ballistics Committee, 2005: 669-677.

DOI: 10.12783/ballistics2017/16965

[2] Bill G. Campbell III, Phil G. Csik, Dawn G. Gregg, John B. HU, et al. Advances in multiple explosively formed penetrator technology. Proceedings of the 41st Annual Bomb & Warhead Technical Meeting. San Diego California. May 15-16 1991. 207-220.

[3] Zhao Chang-xiao, LONG Yuan, Sui Yuan-song. Influence of Initiation methods on formation of integral MEFP warhead parameter[J]. Journal of PLA University of Science and Technology(Natural Science Edition), 2012, 13(5): 559-564.

[4] WU Xiao-rong, HUANG De-wu, WANG Men. Design and experimental study on multiple explosively formed warhead[J]. Transactions of Shenyang Ligong University, 2007, 26(1): 72-74.

[5] Zhao Chang-xiao, LONG Yuan, JI Chong, et al. Numerical simulation and experimental research on integral multiple explosively formed projectile warhead [J]. Acta Armamentarii, 2013, 34(11): 1392-1397.

[6] FAN　Bin, WANG Zhijun, WANG Hui．The numerical simulation of formation process of MEFP [J]．Journal of Projectiles, Rockets, Missiles and Guidance. 2010, 30(1): 124-126.

[7] YANG Bao-liang, CHEN Xiu-wen, SHEN Xiao-li, et al. Numerical Simulation of the MEFP Warhead with the Different Modes Detonation[J]. Journal of Projectiles, Rockets, Missiles and Guidance. 2006, 26(3): 108-112.

[8] Manfred Held. Liners for Shaped Charges [J]. Journal of battlefield technology, 2001, 4(3): 2-11.

[9] Alistar Doig. Some metallurgical aspects of shaped charge liners. of shaped charge liners [J]. Journal of battlefield technology, 1998, 1(1): 1-9.
