Penetration Performance of Shaped Charge Jets Using Insensitive Munition: Simulative and Experimental Studies

Abstract:

The simulation and experimental studies of the Jets obtained from different conical liners from a charge having 56mm-diameter is presented in this paper. An OFHC copper liner of thickness 1 mm and 54 mm-diameters is used for jet formation analysis. Charge ignition is made by using Point detonation method. The simulation results are obtained from Ansysis Autodyn 2-D hydrocode. Experiments are conducted for a charge having 60⁰ conical liner. Flash X-ray Radiography is used for image capturing. The performance capacity of standard shaped charge is predicted by its penetration against steel target. It is observed that kinetic energy of the jet decreases as angle increases, also total energy of the explosive increases and hence the Ratio of the K.E of the jet to the total energy of the explosive decreases as the angle increases. Simulation results are compared with the experimental results. It is observed that simulation results are in favorable agreement within acceptable range of error with the experimental results.

• Periodical: Advanced Materials Research (Volume 1102)
• Pages: 119-123
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1102.119
• Online since: May 2015
• Authors: Mukhtar Ahmed*, Zheng Xiang Huang, A.Q. Malik, Xu Dong Zu, Qiang Qiang Xiao, Munir Ahmed
• Keywords: Flash X-Ray Radiography, Jet Formation, Jet Penetration, Liner, Penetration Depth, Shaped Charge

References

[1] Xu-dong Zu, Zheng-xiang Huang, Wen Zhai, Xin Jia, Performance of Kevlar Fiber-Reinforced Rubber Composite Armour against Shaped-Charge Jet Penetration, Latin American Journal of Solids and Structures, Vol. 11 (2014).

DOI: 10.1590/1679-78251202

[2] Walter, W.P., Zukas, J.A., Fundamentals of Shaped Charges, Wiley, New York, (1989).

[3] Held, M., Backofen, J.E., Penetration of Shaped Charge into water, Proceedings of the 12th International Symposium on Ballistics, San Antonio, Texas. Vol. II (1990) 30-40.

[4] Chick, M.C., Frey, R.B., Trimble, J.J., Bines, A., Jet Penetration in Plexiglas, Proceedings of 8th International Symposium on Ballistics, Orlando, Florida. Vol. II (1994) 21-26.

[5] Lee, E.S., Oh, K. H, Song, S.Y., Penetration of Particulated Shaped Charge Jet into Water, Proceedings of SPIE, High Speed Photography and Photonics, 21st International Congress, Ung Kim. Vol. 2513 (1995) 975-981.

DOI: 10.1117/12.209556

[6] Lee, S., Kim, E.P., Kim, Y., Lee, S.H., Hong, M.H., Noh, J.W., Penetration Performance of Tungsten-Copper Shaped Charge Liner, Proceedings of 22nd International Symposium on Ballistics, Vancouver BC, Canada. (2005) 437-443.

DOI: 10.12783/ballistics2017/17021

[7] Xin Jia, Zheng-Xiang Huang, Xu-Dong Zu, Xiao-Hui Gu, Qiang-qiang Xiao, Theoretical Analysis the Disturbance of the Shaped charge Jet Penetrating a Rubber Fabric Woven composite, International Journal of Impact Engineering. 65 (2014) 69-78.

DOI: 10.1016/j.ijimpeng.2013.11.005

[8] Xiangrong Zhang, Cheng Wu, Fenglei Huang, Penetration of Shaped Charge Jets with Tungsten-Copper and Copper Liners at Same Explosive-to-Liner mass Ratio in Water, Shock Waves. 20 (2010) 263-267.

DOI: 10.1007/s00193-010-0248-0

[9] AUTODYN Explicit Software for Nonlinear Dynamics, v12. 1 (2011).

[10] Jian-ping FU, Zhi-gang CHEN, Xiu-cheng HOU, Shu-qiang Li, Shou-cang Li, Jing-wen WANG, Simulation and Experimental Investigation of Jetting Penetrator Charge at Large Stand-off Distance, Defence Technology 9 (2013) 91-97.

DOI: 10.1016/j.dt.2013.06.001
