Comparative Study of SPWM and HEPWM Techniques for Photovoltaic Inverter

Abstract:

This paper presents an evaluation study of two pwm techniques applied to a three-phase voltage source inverter supplied by photovoltaic (PV) energy sources. A Pspice-based model of the pv array is developed and tested. The power and currant of the pv array versus the voltage is plotted. Then the pv array is connected to a basic three phase voltage source inverter VSI. Two control techniques are used. The first one is the classic sinusoidal pulse width modulation spwm, which is based on the comparison of two signals, the sinusoidal reference and a triangular carrier. The second one is based on the principle of harmonic elimination. The system is simulated using orcad-pspice, the results are given, discussed and compared based on different performance indices (output quality, thd, frequency).

• Periodical: Advanced Materials Research (Volume 1115)
• Pages: 555-559
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1115.555
• Online since: July 2015
• Authors: Douadi Bendib*, F. Akel, M. Chikh, C. Larbes, M. Laour, A. Mahrane
• Keywords: Harmonic Elimination, Maximum Power Point, Power Quality, Pulse Width Modulation, PV Array, Sinusoidal Modulation, Voltage Source Inverter

References

[1] A. Aziz, K. Kassmi, R. Maimouni, F. Olivié, G. Sarrabayrouse and A. Martinez. Symbolization of the Electric Diagram of the Marketed Solar Panels in the Orcad – Pspice Environment. Moroccan Journal of Condensed Mater, Vol. 7, N°1: 38 – 41. (2006).

[2] L. Castañer, S. Silvestre. Modeling photovoltaic systems using spice. John Wiley and Sons. (2002).

[3] A. Mahrane et al. Test bench for Photovoltaic Modules. International Symposium on Environment Friendly Energies in Electrical Applications. Ghardaïa (2010).

[4] M.H. Rashid. Spice for power electronics and electric power. Second edition CRC/Taylor & Francis. (2006).

[5] N. Mohan, M. Tore and P. William. Power electronics. Converters, Applications and Design. john wiley & sons. 2nd ed. New York, (2003).

[6] S.P. Hasmukh and G.H. Richard. Generalized techniques of harmonic elimination and voltage control in thyristor inverters Part 1: Harmonic Elimination. IEEE Trans. Ind. App, IA-9, no3: 310-317. (1973).

DOI: 10.1109/tia.1973.349908

[7] S.P. Hasmukh and G.H. Richard. Generalized Techniques of harmonic Elimination and Voltage Control in Thyristor Inverters Part 2: Voltage Control Techniques. IEEE Trans. Ind. App , IA-10, no5: 666-673. (1973).

DOI: 10.1109/tia.1974.349239

[8] P.N. Enjeti, P.D. Ziogas and J.F. Lindsay. Programmed PWM Techniques to Eliminate Harmonics: A Critical Evaluation". IEEE Trans. Ind. App vol. 26, no2: 302-316. (1990).

DOI: 10.1109/28.54257

[9] J. Vignes. Algorithmes numériques, analyse et mise en œuvre tome 2: Equations et systèmes non linéaires. Technip, Paris. (1980).
