Innovative Applications of Steel Fibres in Concrete Flange of Composite Beam Subjected to Combined Negative Bending and High Axial Tension

Abstract:

The steel-concrete composite beam has become very popular these days and deterioration of the composite beam and its ultimate limit state are often reported in the subjection of combined negative bending and axial tension. Due to the presence of high axial loads, it was given a guideline in a previous research study by experimental investigation such that the failure modes were reinforcement fracture and shear connection failure in limiting the ultimate limit state of the composite beam subjected to combined negative bending and high axial tension rather than concrete failure. Thus, it is important to study in order to implement the strengthening methods with innovative material applications to overcome this problem. It was assumed that the application of steel fibres in the concrete flange will be an excellent contender owing to its in-service and mechanical properties, which is the hypothesis of this research. In order to evaluate this concept, the finite element (FE) models of a composite beam subjected to negative bending and high axial tension, and steel fibre reinforced concrete (SFRC) slab were developed with non-linear material components and validated with relevant experimental studies. Consequently, the plain concrete flange of composite beam was replaced by SFRC flange and studied the failure behaviour of the composite beam subjected to combined negative bending and high axial tension. It was predicted that an improvement in the ultimate limit state and in initial cracking load due to the postponing the failure modes, which are extensively discussed and suggested as it will be a strengthening method of the concrete flange on the composite beam in such cases.

• Periodical: Advanced Materials Research (Volume 1129)
• Pages: 367-374
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1129.367
• Online since: November 2015
• Authors: Mahesan Bavan*, Shahrizan bin Baharom, Siti Aminah Osman
• Keywords: Application of SFRC, Composite Beam with High Axial Tension, Crack Initiation Load, Development of Ultimate Limit Load Carrying Capacity, FE Modelling, Global Behaviours, Local Behaviours

References

[1] G. Vasdravellis, B. Uy, E.L. Tan, B. Kirkland, The effects of axial tension on the Hogging moment region of composite beams, J Constr Steel Res 68 (2012) 20-33.

DOI: 10.1016/j.jcsr.2011.06.017

[2] W. Lin, T. Yoda, N. Taniguchi, Application of SFRC in steel-concrete composite beam subjected to hogging moment, Journal of Construction steel research (2014) 175-183.

DOI: 10.1016/j.jcsr.2014.05.008

[3] T. Yoda, W. Lin, N. Taniguchi, H. Kasano, L. Heang, H. Ge, Comparative study on continuous steel-concrete composite beams with normal and steel fibre reinforced concrete slab. Proceedings of the thirteenth east Asia-Pacic conference on structural engineering and construction, Sapporo, Japan, (2013).

[4] O. Mirza, B. Uy, Effects of steel fibre reinforcement on the behaviour of headed stud shear connectors for composite steel-concrete beams. Advanced steel construction (2009) 72-95.

DOI: 10.18057/ijasc.2009.5.1.5

[5] S.O. Mpegetis, Behaviour and design of steel fibre reinforced concrete slabs, PhD Thesis, Department of Civil and Environmental Engineering, Imperial College London, (2012).

[6] P. Desayi, S. Krishnan. Equation for the stress-strain curve of concrete. ACIJ Proceed. 61(22) (1964) 345-350.

[7] BS EN 1994-1-1, Euro code 4, Design of composite steel and concrete structure; Part 1. 1, general rules and rules for buildings, London (UK); British Standards Institution (2004).

[8] P. Kmiecik, M. Kaminski, Proceedings of conference on modelling of reinforced concrete structures and composite structures with concrete strength degradation taken into consideration in Archives of Civil and Mechanical Engineering VI, Wroclaw, Poland, 2011, pp.623-636.

DOI: 10.1016/s1644-9665(12)60105-8

[9] J. Lubliner, J. Oliver, S. Oller, E. Onate. A plastic-damage model for concrete. International Journal of Solids and Structures (1989) 299-329.

DOI: 10.1016/0020-7683(89)90050-4

[10] N. Gattesco. Analytical modelling of nonlinear behavior of composite beams with deformable connection. J Constr Steel Res (1999) 195-218.

DOI: 10.1016/s0143-974x(99)00026-7

[11] ABAQUS user's manual, version 6. 11, Dassault Systèmes Simulia Corp., Providence, RI, USA.
