Examination of Noxious Emissions of the Welding Process “Cold Metal Transfer (CMT)”

Abstract:

For the examination of noxious emissions, cladding tests were performed according to EN ISO 6847. The filler materials were 1.2 mm diameter wire-electrodes, made of tin bronze, aluminium bronze, austenitic stainless steel, duplex stainless steel and nickel alloy.The low-energy metal transfer welding process, named CMT (cold metal transfer) was examined, on the welding source type Trans Puls Synergic 2700 CMT, of 270 A, produced by the company Fronius, Austria. For sampling welding smoke particles, an Apex type pump was used. For measuring the concentration of gases emitted by welding, a Triple Plus type multi-gas detector was applied.The particulate emission rate is 0.500 mg / m3 in the breathing zone, according to ISO 10882-1. For comparison, the measured emission rate is from 0.877 to 2.513 mg / m3 in the welding zone, according to ISO 15011-1. The concentration of the emitted gases is in the ranges: 0.14 to 0.16% CO2; 0.1-0.2 ppm NO2; 0-15 ppm H2; 0-5 ppm CO. These concentration levels are below the exposure limits (8 hours per day, five days a week): 5% CO2; 1.0 ppm NO2; 30 ppm CO. In conclusion, the emissions from the CMT welding process are without health risk for the welder.

• Periodical: Advanced Materials Research (Volume 1138)
• Pages: 25-30
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1138.25
• Online since: July 2016
• Authors: Victor Verbiţchi*, Radu Cojocaru, Lia Nicoleta Boţilă, Cristian Ciucă
• Keywords: Bronze, CMT, Cold Metal Transfer, Exposure Limits, Gas Concentration, Gas Emissions, Nickel Alloy, Noxious Emissions, Particulate Emission Rate, Stainless Steel, Welding Fumes

References

[1] V.E. Spiegel-Ciobanu, BGI 593. Noxious substances in welding and allied processes (German: Schadstoffe beim Schweisen und bei verwandten Verfahren),. Berufsgenossenschaft Holz und Metall, Mainz, Germany. (2012).

[2] V.E. Spiegel-Ciobanu, Chromium and nickel in welding and allied processes- Some important aspects, IIW Doc. VIII 1799-97,. International Institute of Welding (1997).

[3] P.J. Cunat, Chromium in stainless steel welding fumes, IIW Doc. VIII-1973-03, (2003).

[4] G. McMillan, Lung cancer and electric arc welding, IIW Doc. 1988-05, (2005).

[5] J. Matusiak (Institute of Welding, Gliwice, Poland); A. Wycislik (Silesian University of Technology, Katowice, Poland): The influence of technological conditions on the emission of welding fume due to welding of stainless steels,. METALURGIJA, Vol. 49, (2010).

DOI: 10.15407/tpwj2016.06.27

[6] K. Carpenter, B.J. Monaghan, J. Norrish: Analysis of fume formation rate and fume particle composition for gas metal arc welding (GMAW) of plain carbon steel using different shielding gas compositions,. ISIJ International, Vol. 49 (2009).

DOI: 10.2355/isijinternational.49.416

[7] Il Je Yu, Kyung Seuk Song, Seung Hee Maeng, Soo Jin Kim, e. a.: Inflamatory and genotoxic responses during 30-day welding-fume exposure period,. Toxicology Letters, Volume 154, (2004), Issues 1-2, 105-115.

DOI: 10.1016/j.toxlet.2004.07.009

[8] OSHA - Occupational Safety & Health Administration: OSHA Annotated PELs. Permissible Exposure Limits, (2015). www. osha. gov.

DOI: 10.1093/obo/9780199756797-0213

[9] Fronius GmbH: Product Catalogue. Welding source TransPuls Synergic 2700 CMT, (2015).

[10] Casella Cell Ltd.: APEX Personal air sample pump. User manual, (2012).

[11] Crowcon Ltd.: Multiple Gas Detector Triple Plus +IR. User manual, (2012).

[12] EN ISO 10882-1: 2011. Health and safety in welding and allied processes- Sampling of airborne particles and gases in the operator's breathing zone- Part 1: sampling of airborne particles.

DOI: 10.3403/02021688u

[13] EN ISO 10882-2: 2000. Health and safety in welding and allied processes - Sampling of airborne particles and gases in the operator's breathing zone - Part 2: sampling of gases.

DOI: 10.3403/02009305

[14] EN ISO 15011-1: 2009. Health and safety in welding and allied processes - Laboratory method for sampling fume and gases - Part 1: Determination of fume emission rate during arc welding and collection of fume for analysis.

DOI: 10.3403/30140388

[15] EN ISO 15011-2: 2009. Health and safety in welding and allied processes - Laboratory method for sampling fume and gases - Part 2: Determination of emission rates of carbon monoxide (CO), carbon dioxide (CO2), nitrogen monoxide (NO) and nitrogen dioxide (NO2) during arc welding, cutting and gouging.

DOI: 10.3403/30140392
