Studies on Structural, Infrared and Optical Properties of Cobalt Ferrite Thin Film Grown by Spray Pyrolysis Technique

Abstract:

Thin film of cobalt ferrite has been deposited on glass substrate by a chemical spray pyrolysis technique using methanol solutions at 400^◦C substrate temperature. The uniformly deposited thin film were annealed at 500 ^◦C and studied their structural, infrared and optical properties using X-ray diffraction (XRD), Fourier transform infrared spectroscopy (FTIR) and UV-Vis spectroscopy (UV-Vis), respectively. The X-ray diffraction patterns revealed single phase cubic spinel structure with space group Fd-3m. The fundamental absorption bands related to octahedral and tetrahedral sites were confirmed by Fourier-transform infrared spectroscopy (FTIR) spectrum.The formation of cubic spinel crystal structure of the CoFe₂O₄ thin filmwere confirmed from exhibited strong absorption peaks around 530.21 and 451.48 cm⁻¹ by FT-IR spectra.The optical properties of the deposited thin film were studied by an absorbance spectrum found at 315 nm. The value of energy bandgap (2.4 eV) wasinvestigated by Tauc plot.The obtained results indicate the fabricated thin film is promising material for various applications.

• Periodical: Advanced Materials Research (Volume 1169)
• Pages: 43-48
• DOI: https://doi.org/10.4028/p-f41120
• Online since: March 2022
• Authors: Balasaheb Kharat*, Vikas Magar, Sagar Rathod, A.A. Chaudhari, V.B. Malode
• Keywords: Cobalt Ferrite, FTIR, Spray Pyrolysis, UV-Vis Spectroscopy, XRD

References

[1] Bagade, A., et al., Assessment of structural, morphological, magnetic and gas sensing properties of CoFe2O4 thin films. Journal of colloid and interface science, 2017. 497: pp.181-192.

DOI: 10.1016/j.jcis.2017.02.067

[2] Kumbhar, S., et al., Effect of Ni content on the structural, morphological and magnetic properties of spray deposited Ni–Zn ferrite thin films. Materials Research Bulletin, 2015. 67: pp.47-54.

DOI: 10.1016/j.materresbull.2015.02.056

[3] Sun, J., et al., Synthesis of the nanocrystalline CoFe2O4 ferrite thin films by a novel sol–gel method using glucose as an additional agent. Materials Science and Engineering: B, 2012. 177(2): pp.269-273.

DOI: 10.1016/j.mseb.2011.12.017

[4] Zaquine, I., H. Benazizi, and J. Mage, Ferrite thin films for microwave applications. Journal of Applied Physics, 1988. 64(10): pp.5822-5824.

DOI: 10.1063/1.342218

[5] Pham, T.N., T.Q. Huy, and A.-T. Le, Spinel ferrite (AFe2O4)-based heterostructured designs for lithium-ion battery, environmental monitoring, and biomedical applications. RSC Advances, 2020. 10(52): pp.31622-31661.

DOI: 10.1039/d0ra05133k

[6] Goktas, A., F. Aslan, and A. Tumbul, Nanostructured Cu-doped ZnS polycrystalline thin films produced by a wet chemical route: the influences of Cu doping and film thickness on the structural, optical and electrical properties. Journal of Sol-Gel Science and Technology, 2015. 75(1): pp.45-53.

DOI: 10.1007/s10971-015-3674-8

[7] Phua, L., et al., Structure and magnetic characterizations of cobalt ferrite films prepared by spray pyrolysis. Thin Solid Films, 2009. 517(20): pp.5858-5861.

DOI: 10.1016/j.tsf.2009.03.065

[8] Mwakikunga, B.W., Progress in ultrasonic spray pyrolysis for condensed matter sciences developed from ultrasonic nebulization theories since michael faraday. Critical reviews in solid state and materials sciences, 2014. 39(1): pp.46-80.

DOI: 10.1080/10408436.2012.687359

[9] Jung, D.S., S.B. Park, and Y.C. Kang, Design of particles by spray pyrolysis and recent progress in its application. Korean Journal of Chemical Engineering, 2010. 27(6): pp.1621-1645.

DOI: 10.1007/s11814-010-0402-5

[10] Sutka, A., et al., Ethanol monitoring by ZnFe2O4 thin film obtained by spray pyrolysis. Sensors and Actuators B: Chemical, 2013. 176: pp.330-334.

DOI: 10.1016/j.snb.2012.09.061

[11] Leng, J., et al., Advances in nanostructures fabricated via spray pyrolysis and their applications in energy storage and conversion. Chemical Society Reviews, 2019. 48(11): pp.3015-3072.

DOI: 10.1039/c8cs00904j

[12] Shamala, K., L. Murthy, and K.N. Rao, Studies on optical and dielectric properties of Al2O3 thin films prepared by electron beam evaporation and spray pyrolysis method. Materials Science and Engineering: B, 2004. 106(3): pp.269-274.

DOI: 10.1016/j.mseb.2003.09.036

[13] Kretzschmar, B., et al., Cobalt and manganese carboxylates for metal oxide thin film deposition by applying the atmospheric pressure combustion chemical vapour deposition process. RSC advances, 2018. 8(28): pp.15632-15640.

DOI: 10.1039/c8ra02288g

[14] Khaja Mohaideen, K. and P. Joy, High magnetostriction and coupling coefficient for sintered cobalt ferrite derived from superparamagnetic nanoparticles. Applied Physics Letters, 2012. 101(7): p.072405.

DOI: 10.1063/1.4745922

[15] El-Masry, M.M., R. Ramadan, and M. Ahmed, The effect of adding cobalt ferrite nanoparticles on the mechanical properties of epoxy resin. Results in Materials, 2020. 8: p.100160.

DOI: 10.1016/j.rinma.2020.100160

[16] Zhang, Y., et al., Composition and magnetic properties of cobalt ferrite nano-particles prepared by the co-precipitation method. Journal of Magnetism and Magnetic Materials, 2010. 322(21): pp.3470-3475.

DOI: 10.1016/j.jmmm.2010.06.047

[17] Mohammadifar, Y., et al., The synthesis of Co1− xDyxFe2O4 nanoparticles and thin films as well as investigating their magnetic and magneto-optical properties. Journal of magnetism and magnetic materials, 2014. 366: pp.44-49.

DOI: 10.1016/j.jmmm.2014.04.017

[18] Brucker, C., Magneto-Optical Thin Film Recording Materials in Practice, in Handbook of Magento-Optical Data Recording. 1995, Elsevier. pp.279-361.

DOI: 10.1016/b978-081551391-9.50007-5

[19] Jadhav, G.L., et al., Effect of magnesium substitution on the structural, morphological, optical and wettability properties of cobalt ferrite thin films. Physica B: Condensed Matter, 2019. 555: pp.61-68.

DOI: 10.1016/j.physb.2018.11.052

[20] Andhare, D.D., et al., Effect of Zn doping on structural, magnetic and optical properties of cobalt ferrite nanoparticles synthesized via. Co-precipitation method. Physica B: Condensed Matter, 2020. 583: p.412051.

DOI: 10.1016/j.physb.2020.412051

[21] Patade, S.R., et al., Impact of crystallites on enhancement of bandgap of Mn1-xZnxFe2O4 (1≥ x≥ 0) nanospinels. Chemical Physics Letters, 2020. 745: p.137240.

DOI: 10.1016/j.cplett.2020.137240
