Finite Element Analysis of Sieve Box Structure in Fluidized Bed

Abstract:

The sieve box is the major working part in fluidized bed, which bears the repeating dynamic loading. It generally works in severe condition, and the strength is a problem. In this paper, the vibration of the sieve box was analyzed with finite elemental method. Firstly, a 3D model of the box was constructed by PRO/E. Then the modal analysis and harmonic response of the model were investigated using ANSYS WORKBENCH. Based on the modal analysis theory，some parts of the sieve box were structurally optimized to avoid resonance. The simulation procedure adopted in the study and the achieved results could definitely facility the fluidized bed design and improve the design efficiency.

• Periodical: Advanced Materials Research (Volumes 118-120)
• Pages: 497-501
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.118-120.497
• Online since: June 2010
• Authors: Bin Li, Jin Cai, Xiang Wei Kong, Zhao Feng Song
• Keywords: Finite Element Model (FEM), Fluidized Bed, Harmonic Response, Modal Analysis, Sieve Box

References

[1] Y.X. Xu, Z.M. Huang, L.J. Zhao, S.J. Jin and J. Yuan: Journal of Shen Yang polytechnic university, (1999), 21(6). 1-5.

[2] M.Y. Gong. Research on large vibrating screen system and structural dynamics. ( Unpublished thesis for Master's degree, Yanshan University, Qinhuangdao, 2008).

[3] B.C. Wen and F.X. Liu. Theory and application of vbration machinery. Beijing: Machinery Industry Press, (1982).

[4] H.X. Zhang. The dynamics analysis and study of large-sized linear vibration screener. (Unpublished thesis for Master's degree, Qingdao University of Science & Technology, Qindao, 2009).

[5] D.X. Cheng. Mechanical design manual (The fifth edition). Beijing: Chemical IndustryPress(2008).

[6] L.J. Wu and H.B. Li: Mechanical Engineer, 2004, (8), 45-47.
