Research on Simulation Platform Architecture for Noise Reduction of Electric Locomotive Wheel

Abstract:

Wheel/rail rolling noise is the main source of noise from railway operations, it is at least as important as aerodynamic noise. In this paper, the makeup of unit modules of CAE(Computer Aided Engineering) simulation platform for of railway passenger car and its function frame are given. Based on finite element method, boundary element method, the structural model, interior acoustic cavity and acoustics model of electric locomotive wheel were analyzed by Nastran and Sysnoise software. This paper is imposed sinusoidal excitation on the wheel, and then the laying of the viscoelastic layer and optimization of damping-wheel, obtain the wheel’s structure of the vibration noise radiation.The analysis result shows that the laying of the viscoelastic layer can reduce wheels radiation noise, and the noise can be reduced from 0.27 to 8.62 dB.Practical application indicated this simulation platform can supply effective technology support for the development of product.

• Periodical: Advanced Materials Research (Volumes 121-122)
• Pages: 940-944
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.121-122.940
• Online since: June 2010
• Authors: Si Qun Ma, Wan Li Zhao, Ya Na Li, Xue Fei Huang, Xiao Peng Wu, Xuan Chen, Lin Feng Li, Qing Hu Kang
• Keywords: BEM, Finite Element Model (FEM), Layer, Locomotive, Noise Reduction, Rail, Wheel

References

[1] Thompson and P-E Gautier. Review of research into wheel/rail rolling noise reduction Proc. IMechE Vol. 220 Part F: J. Rail and Rapid Transit, pp.49-54, 385-406.

DOI: 10.1243/0954409jrrt79

[2] FAN Rongping , SUN Xu , MENG Guang , et al . Study on Noise Characteristics within the High Speed Train[J]. Journal of Vibration Engineering , 2004, 17(Supplement): 1097-1100. in Chinese.

[3] XIAO Yougang , TIAN Hongqi , ZHANG Hong. Prediction of Interior Aerodynamic Noise of High-Speed Train Cab [J]. Journal of Traffic and Transportation Engineering , 2008 , 8 (3) : 10-14. in Chinese.

[4] Chai xudong, Li bohu, Xiong guangleng etc. Research and Implementation on Collaborative Simulation Platform for Complex Product, computer integrated manufacturing system, -CMIS, 2002, 8 ：(7) 580-584.

[5] Yoshio Kojima, Mechanical CAE in Automotive Design, R&D Reviw of Toyota CRDL Vol. 35 No. 4, pp.1-10, (2002).

[6] SHI Yu , XIAO Yougang , KANG Zhicheng. Interior Noise Investigation for a Passenger Room of a High Speed Train under Wheel2Rail Excitation [J] . Journal of Vibration and Shock , 2009 , 28 (1) : 95-98. in Chinese.

[7] XIAO Yougang , KANG Zhicheng. Acoustic Cont ribution Analysis of Passenger Room of High2Speed Train under Wheel2Rail Excitation [J] . Journal of South China University of Technology , 2009 , 37 (2) : 98-101. in Chinese.

[8] XIE Suming , LI Tao , LI Xiaofeng , ZHAO Wenzhong. Prediction on the Vibration and Noise of High-Speed Train Structure and Research on the Noise Reduction Technology [J] . China Railway Science , 2009 , 30 (6) : 77-83. in Chinese.
