Application of Ultrasonic Wave Technology to Evaluate the Corrosion Depth of Concrete in Acid Rain Environment

Abstract:

Deterioration of concrete exposed to acid rain environment will take a significant effect on the load carrying capacity and durability of the concrete structures. To evaluate the corrosion depth of concrete in acid rain environment, an experimental study was performed with ultrasonic wave technology in the laboratory. In the experiment, sulfate and nitric acid solutions are mixed to simulate the 3 pH levels (pH 3.5, pH 2.5 and pH 1.5) acid rain environments respectively. After being exposed to the simulated acid rain solutions for certain periods, a series of tests (including ultrasonic nondestructive test, Computerized Tomography (CT) test, compressive tests, etc.) were conducted. Damage depth, mass loss, axial compressive strength, and meso-structure of the concrete specimen under different corrosion state were achieved. It was shown that ultrasonic testing is a reliable nondestructive method to measure the damage depth of concrete. A bilinear regression model is proposed to predict the damage depth of concrete, which is in good correlation with testing results from both ultrasonic testing and CT test.

• Periodical: Advanced Materials Research (Volumes 129-131)
• Pages: 128-133
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.129-131.128
• Online since: August 2010
• Authors: Ying Fang Fan, Zhi Qiang Hu, Jiang Lin Liu
• Keywords: Concrete, Corrosion Depth, CT, Simulated Acid Rain Environment, Ultrasonic Wave Technology

References

[1] Y.F. Fan, Z.Q. Hu, Y.Z. Zhang, J.L. Liu. Deterioration of compressive property of concrete under simulated acid rain environment. Construction and Building Materials. (2010), in press.

DOI: 10.1016/j.conbuildmat.2010.04.002

[2] T. Sato, K. Takewaka and S. Kamata. Experimental study on deterioration of concrete structures due to acid-rain. Proceedings of the Second International Conference on Concrete under Severe Conditions. (1999) pp.555-564.

DOI: 10.2208/jscej.1999.634_11

[3] Y. Kishimoto, S. Hokoi, K. Harada, F. Watanabe, S. Takada. Influences of acid rain on the neutralization process. Proceedings of the 3rd International Building Physics Conference - Research in Building Physics and Building Engineering. (2006).

[4] L.H. Kong, G. James. Concrete deterioration due to acid precipitation. ACI Materials Journal. Vol. 84(2) (1987) pp.110-116.

[5] N.I. Fattuhi, B.P. Hughes. The performance of cement paste and concrete subjected to sulphuric acid attack. Cement and Concrete Research. Vol. 18(4) (1988) pp.545-553.

DOI: 10.1016/0008-8846(88)90047-6

[6] H. Okochi, H. Kameda, S. Hasegawa, N. Saito, K. Kubota, M. Igawa. Deterioration of concrete structures by acid deposition- an assessment of the role of rainwater on deterioration by laboratory and field exposure experiments using mortar specimens. Atmospheric Environment. Vol. 34 (2000).

DOI: 10.1016/s1352-2310(99)00523-3

[7] S.A. Abo-Qudais. Effect of concrete mixing parameters on propagation of ultrasonic waves. Construction and Building Materials. Vol. 19 (2005) pp.257-263.

DOI: 10.1016/j.conbuildmat.2004.07.022

[8] T. Kanazu, T. Matsumura, T. Nishiuchi, T. Yamamoto. Effect of simulated acid rain on deterioration of concrete. Water, Air, and Soil Pollution. Vol. 130 (1-4 III) (2001) pp.1481-1486.

DOI: 10.1007/978-94-007-0810-5_94

[9] T.J. Wang, L.S. Jin, Z.K. Li, K.S. Lam. A modeling study on acid rain and recommended emission control strategies in China. Atmospheric Environment. Vol. 34 (2000) pp.4467-4477.

DOI: 10.1016/s1352-2310(00)00101-1

[10] S. Xie, L. Qi, D. Zhou. Investigation of the effects of acid rain on the deterioration of cement concrete using accelerated tests established in laboratory. Atmospheric Environment. Vol. 38 (2004) pp.4457-4466.

DOI: 10.1016/j.atmosenv.2004.05.017
