Dynamic Multibody Simulation of a 6-DOF Robotic Arm

Abstract:

Based on the kinematic model with Cartesian structure, Newton-Euler like algo¬rithm being employed to solve the nonlinear equations of motion and constraints in real-time application, and dynamic multibody simulation, a novel integrated design for a 6-DOF ro¬bot is investigated, and the interfaces required for the implementation of different computer aided engineering (CAE) tools used in the design is addressed [1].The presented method in this paper was analyzed and verified by the numerical and physical 6-DOF robot model, the result shows that the topologic projection me-thod [2] is stable. The design experience accumulated will be very useful for the future product de-sign.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 1001-1004
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.1001
• Online since: October 2010
• Authors: Bin Li, Xi Fan Yao, Chun Bao Wang, Hui Dong Lou
• Keywords: Multibody, Prototype, Topological Projection Algorithm

References

[1] W Kruger: Mechanics of Structures and Machines, vol. 30 (2002) no. 4, pp.493-526.

[2] D Vlasenko and R Kasper: Multibody System Dynamics, (2009), pp.297-319.

[3] T Lesprier, P Mognol, B Furet and J. Y Hascoet: Journal of Engineering Manufacture, vol. 218 (2004) no. 10, pp.1423-1428.

DOI: 10.1243/0954405042323478

[4] B Li,X. P Hu and H Wang: Journal of Adv Manuf Technol, vol. 30 (2006) no. 3, pp.221-226.

[5] B. H Liu and K. D Huang: Journal of System Simulation, vol. 16 (2004) no. 6, pp.1150-1153.

[6] B. J Yang and G. Q Cai: Journal of Harbin Institute of Technology, vol. 41 (2009) no. 11, pp.103-105.

[7] D.S. Bae and J.K. Lee: Computer methods in applied mechanics and engineering, vol. 187 (2000) no. 1-2, pp.337-350.

[8] M Callegari and M. C Palpacelli: Meccanica, vol. 43 (2008) no. 2, pp.133-151.
