Development of Hydraulic Control Jam Release Device for Workover

Abstract:

Developed a device used to assist workover rig in lifting stuck tubing strings from the well during workover treatment, it can create well economic benefit for oil field. The device adopts remote hydraulic control, which is safe and reliable. The structure and work principle of the device is illustrated. The jam release device is mainly made up of hydraulic cylinders, hydraulic pump and hydraulic control valves. With the coordination between lifting hydraulic cylinders and hydraulic slips, the device can lift tubing strings from the well. The important loading unit of the device is analyzed by finite element. The working pressure is made from 5MPa to 20MPa, corresponding to lifting force range of 229kN to 915.6kN, which can meet the jam release force in workover treatment.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 1010-1013
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.1010
• Online since: October 2010
• Authors: Guang Zheng Jia, Shuo Wang, Fu Chen Zhang
• Keywords: Finite Element Computation, Jam Release Device, Workover Treatment

References

[1] H.G. Nie and X.H. Wang: Well service engineering of downhole operation in Oil and gas field. (Petropleum Industry Press China 2002). (in Chinese).

[2] G.Z. Jia, H.J. Liu and D.H. Jia: Oil Field Equipment, Vol. 27 (1998) No. 1, pp.30-33. (In Chinese).

[3] S.Y. Fang and Y.J. Wang: Shengli Study Journal, Vol. 12 (1998) No. 4, pp.23-25. (In Chinese).

[4] D. Wang, X.J. Chen and Y.Z. Liu: Petroleum Machinary, Vol. 27 (1999) No. 5, pp.41-42. (In Chinese).

[5] S.G. Qiao and R.H. Ma: Petroleum Machinary, Vol. 35 (2007) No. 7, pp.41-43. (In Chinese).

[6] K.S. Chen: Hydraulic and pneumatic transmission. (Wuhan Technical University Press China 2007), pp.27-28. (In Chinese).
