The Dynamics Simulation of Braking Process on Automobile Disc Brake

Abstract:

For a certain type of automobile disc brakes, brake discs and friction linings were modeled by Pro/E. The dynamics simulations of braking process on disc brake were performed by the frictional contact algorithm and nonlinear finite element method. Distribution of stress, strain and displacement on the brake parts were investigated with different initial velocity. Analysis results shown that redistributions of stress and strain had occurred on the face of brake disc and friction linings in braking process. Meanwhile, the increased initial velocity resulted in increased stress and stain. Besides the stress concentrations appeared in brake disc role and friction lining corners at the beginning of braking, however, stress and stain became uniform along the braking. Analysis results provided the research of the optimum design and testing of disc brake with theoretic gist. And some improvement measures to the structure of disc brake were proposed.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 2658-2661
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.2658
• Online since: October 2010
• Authors: Chuan Qi Fu, Zhou Wang, Bin Li, Chi Yu
• Keywords: Analysis of Strain, Analysis of Stress, Disc Brake, Dynamic Simulation, Finite Element Model (FEM)

References

[1] J.M. Huang, C.H. Gao and X.Z. Lin: Acta Mechanical Solid Sinica, Vol. 28 (2007) No. 3, pp.297-302. (In Chinese).

[2] R.H. Shen, D.P. Zou and G.Y. Li: Machinical Research & Application, Vol. 12 (1999) No. 1, pp.19-21. (In Chinese).

[3] Z. Pan: Finite Element Analysis and Application (Tsinghua University Press, Beijing 2004), pp.20-25.

[4] J. Zhao, J.Y. Chang and J.Q. Chen: Journal of Beijing Institute of Petro-chemical Technology, Vol. 11 (2003) No. 4, pp.45-48. (In Chinese).

[5] Rudolf, W.L. ZHANG and M.Z. Chen: Automobile Brake System Analysis and Design (Beijing: Mechanical Industry Press, CHINA 1985), PP. 201-210.

[6] Y. YILDIZ and M. DUZGUN: International Journal of Automotive Technology, Vol. 11 (2010) No. 1, pp.133-138.
