On Cutting Process of Stainless Steel Fiber with Complex Surface Morphology

Abstract:

To meet the increasing application requirements of stainless steel fibers with rough surface morphology, a self-made multi-tooth tool which can bifurcate chip during the cutting process was utilized to manufacture stainless steel fibers. The novel cutting method can achieve efficient processing of continuous stainless steel fibers with complex surface morphology. The influence of cutting parameters (back engagement ap and feed rate f ) on forming process of fibers’ surface morphology was studied. The cutting experiments were carried out under the condition of selected tool and fixed workpiece rotating speed. The results show that: the surface morphology of stainless steel fiber is simultaneously effected by ap,and feed rate f .Between them, ap has more significant effect on it. In order to obtain stainless steel continuous fibers with coarse surface morphology, the optimum cutting parameters were recommended as follows: ap∈(0.1-0.2) mm, f ∈(0.1 -0.17) mm/r.

You might also be interested in these eBooks

Manufacturing Engineering and Automation I

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 139-141)

Pages:

634-638

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.139-141.634

Citation:

Cite this paper

Online since:

October 2010

Authors:

Biao Tang, Yong Tang, Rui Zhou, Zhen Ping Wan

Keywords:

Cutting Parameter, Multi-Tooth Cutting, Stainless Steel Fiber, Surface Morphology

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Raeissi K, Tufani A, et al:. Journal of the Electrochemical Society, Vol. 155 (2008) No. 12, pp.783-790.

Google Scholar

[2] Guillaum e Tiberghien: Melliand-China, (2006) No. 3, pp.14-16.

Google Scholar

[3] P. Guo, Y.A. Yang, et al: Powder Metallurgy Industry, Vol. 14 (2004) No. 3, pp.13-15.

Google Scholar

[4] Z.P. Wan, Y. Tang and F.Y. Zhang: Key Engineering Materials, (2006) No. 315/316, pp.666-670.

Google Scholar

[5] Z.P. Wan, Y. Tang, Y.J. Liu and W.Y. Liu: Journal of Materials Processing Technology, Vol. 189 (2007) No. 7, pp.273-278.

Google Scholar

[6] Z.S. He, J. Wang, Y. Tang, et al: The Chinese Journal of Nonferrous Metals, Vol. 19 (2009) No. 6, pp.1105-1112. (In Chinese).

Google Scholar

[7] W. Zhou, Y. Tang, Z.P. Wan, et al: Journal of South China University of Technology: Natural Science Edition, Vol. 36 (2008) No. 4, pp.23-28. (In Chinese).

Google Scholar

[8] Z.F. Chen, Z.X. Zeng, et al: Journal of South China University of Technology: Natural Science Edition, Vol. 29 (2001) No. 6, pp.31-35. (In Chinese).

Google Scholar

[9] Z.P. Wan, Y.J. Liu, Y. Tang, et al: Chinese Journal of Mechanical Engineering, Vol. 41 (2005) No. 3, pp.211-215. (In Chinese).

Google Scholar
