An Analysis of Drawing Process in Stamping Die Design for the Wheel Hub

Abstract:

Based on Finite Element Analysis (FEA) module of Dynaform software, the paper made numerical simulation of a wheel hub’s stamping process in the method of elastic-plastic flow, pointed out the behavior of deformation of stamping process, predicted and prevented stamping defect such as crack in the process, and calculated the degree of resilience. Consequently three forming numerical simulation schemes have been designed respectively, more feasible process parameters has been achieved in comparison with the features of each scheme.

• Periodical: Advanced Materials Research (Volume 142)
• Pages: 107-111
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.142.107
• Online since: October 2010
• Authors: Bai Liu
• Keywords: Drawing, Simulation, Stamping

References

[1] Yuan dingguo, Yu chunming: Mold Industry Vol. 33(2007) No. 4, pp.16-19.

[2] J.H. Vogel, D. Lee: Int. J. Mech. Sci. Vol. 32(1990), pp.86-91.

[3] Dong ying, Zhang jinchung, Ying lin. Metal Working Technology(2008) No. 8, pp.80-82.

[4] Zhou jie, Hu jianjun: Chinese Mechanical Engineering Vol. 14 (2003) No. 1, pp.20-22.

[5] VIKRAM V, BRAD K: Journal of Engineering Materials and Technology(2003) No. 4, pp.125-131.

[6] Liu Yuqi, Li Zhigang: Acta Mechanica Solida Sinica. (2004) No. 17, pp.58-64.

[7] F.K. Chen, Y. C. Liao: Int J Adv Manuf. Technol Vol. 19 (2002), p.253–259.

[8] S. Yossifon: J. Mater. Proc. Tech. Vol. 33 (1992), pp.110-114.
