Simulation of Temperature Field during 7022 Al Alloy Friction Stir Welding process Based on Dual-Source

Abstract:

Numerical simulation of temperature field on friction stir welded 7022 aluminum alloy was studied in this paper. A new dual-source model has been designed and applied to investigate the variation of temperature field over time. Result shows that temperature of the nodes along the welding line increased at first and then decreased, the highest nodal temperature of 524°C presents at the ending position. Temperature of the nodes perpendicular to the welding line rises rapidly when the source arrived and falls rapidly when it left, and then cools to room temperature linearly when the source is removed. Simulative result predicts large temperature difference on the plates, and thermal pretreatment should be conducted before welding.

• Periodical: Advanced Materials Research (Volume 142)
• Pages: 63-67
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.142.63
• Online since: October 2010
• Authors: D.L. Shao, W.Z. Lu, D.Z. Wen, H.F. Wang, Ming Min Huang
• Keywords: 7022 Aluminum Alloy, Dual-Source Model, Friction Stir Welding (FSW), Temperature Field Simulation

References

[1] LUAN Guohong, GUAN Qiao: Electric Welding Machine Vol. 35 (2005), pp.8-13.

[2] Miles M P, Decker B J and Nelson T W.: Metal. and Mater. Trans. Vol. 35 (2004), pp.3461-3468.

[3] Huseyin Uzun, Clausio Dalle: Material and Design Vol. 26(2005), pp.41-46.

[4] G. Buffa, J. Hua, R. Shivpuri and L. Fratini: Mater. Sci. and Eng. A Vol. 419 (2006), pp.389-396.

[5] Wang Hongfeng, Zuo Dunwen: J. of Nanjing Univ. of Aeronautics and Astronautics Vol. 26 (2010), pp.173-179.

[6] M. Song: Int. J. of Mach. Tools and Manuf. Vol. 43 (2003), pp.605-615.

[7] Li Ting: Study on friction stir welding of 2024 aluminum alloy (Tsinghua University, Beijing 2007).

[8] C.M. Chen, R. Kovacevic: Int. J. of Mach. Tools and Manuf. Vol. 43 (2003), pp.1319-1326.
