Finite Element Analysis on Stress and Strain of Protected Fiber Bragg Grating

Abstract:

The stresses and strains on the protected FBG and protected layer under varied temperature were analyzed in theory. In order to verify the theoretical analysis of stress and strain,a finite element analysis software(ANSYS) was used to simulate the stresses and strains on the protected FBG and protected layer. Both simulation and theoretical analysis are show that the strain and stress on protected layer in r direction decreases with the increasing of radius(r), while the strain and stress in direction increases with the increasing of radius(r) . The results of theoretical analysis matches the ones form simulations well.

• Periodical: Advanced Materials Research (Volumes 148-149)
• Pages: 1639-1642
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.148-149.1639
• Online since: October 2010
• Authors: Jian Feng Xie
• Keywords: Finite Element Analysis (FEA), Protected FBG, Strain, Thermal Stress

References

[1] P. Feng, X. Z. Lu , L. P. Ye, Experimental research and finite element analysis of square concrete columns confined by FRP sheets under uniaxial compression, Proc. 17th Australasian Conference on the Mechanics of Structures and Materials. Gold Coast, Australia, Jun, 2002. 71~76.

[2] Cho, S. -S., Han, B. K., Lee, J. -H., Chang, H. and Kim, B.K. (2005b). Fatigue durability assessment of full-bead of mls gasket using finite element analysis. Int. J. Automotive Technology 6, 5, 513−517.

[3] Chyuan, S. -W. (2000). Finite element simulation of a twincam 16-valve cylinder structure. Finite Elements in Analysis and Design, 35, 199−212.

DOI: 10.1016/s0168-874x(00)00002-0

[4] Xie Jian-feng 2007 Research on Fiber Protected Technics and Temperature Sensing Properties of Smart Structure [D] Nanchang university. (in Chinese).

[5] Xie Jian-feng, Hua Zhang, Zhengqiang Zhu et al. A study of the temperature sensitivity of fiber Bragg gratings after metallization, Smart Mater. Struct. 16 (2007) 1837–1842.

DOI: 10.1088/0964-1726/16/5/039

[6] Xie Jian-feng, The Research on Sensing Properties of Protected Fiber Bragg Grating based on Stress Analysis, have submitted ICAMMP (2010).

[7] Chen C J 1996 Elastic Mechanics (Lanzhou: Lanzhou University Press) p.467 (in Chinese).

[8] Shyu C T and Wang L 1994 Sensitive linear electric current measurement using two metal-coated single-mode optical fibers J. Lightwave Technol. 12 2040–8.

DOI: 10.1109/50.336070

[9] LIAO Yan2biao. Fiber Optics[M] . Beijing : Tsinghua University Press , 2000 , 197-205. (in Chinese).

[10] .

[14] HE Jian-bo , WU Xiao-an , HUAN Hui , et al. A review of study of elec-troplating of amorphous Ni-P alloy and prospects of its applications [J ] . J of Zhejiang University of Technology 1999 , 27(1) : 62-70. (in Chinese).
