Numerical Simulation in Deep Drawing of Cylindrical Cup with Circular Diving Equally Small Holes on Edge of Circle Blank

Abstract:

Deep-drawing is one of the most important methods to form sheet metal ,but wrinkling and fracture are the main failure modes in sheet-metal forming. Blank shape is important for deep-drawing because of an effective way to promote deep formability sheet metal .This paper presents an attempt to determine the effect of circle blank with circular diving equally small hole on edge of circle blank on the fracture and wrinkling and was investigated using 08Al sheet metal .The circular blank with small hole of diameter = was analyzed to eliminate wrinkling and fracture in deep-drawing .The aim of this study is to investigate the circular diving equally small hole on edge of circle blank on formability in the deep-drawing process and to obtain useful date from the industrial field .The experiment show that limit formability promote with punching small holes on circle blank in deep-drawing process.

• Periodical: Advanced Materials Research (Volumes 148-149)
• Pages: 769-773
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.148-149.769
• Online since: October 2010
• Authors: Yu Qing Shi
• Keywords: Blank with Small Holes, Cylinder Cup, Deep Drawing, Formability, Numerical Simulation

References

[1] Yuqing Shi, Lingfeng Li . Journal of Plasticity Engineering , Vol. 16, No. 1 (2009), pp.12-17(in Chinese).

[2] S. -T. Oh,H. -J. Chang K.H. Oh andH.N. Han. Metals and Materials International, Vol. 12, No. 2(2000), pp.121-129.

[3] S.S. Kang D.H. Park B.K. Choi and S.B. Park. Metals and Materials International, Vol. 7, No. 2(2001), pp.133-142.

[4] Tung-Sheng Yang . Int J Adv Maunf Techno. lVol. 37(2008), P58-64.

[5] L. Gunnarson,E. Schedin. Journal of Material Process Technology, Vol. 114, No. 1(2001), P168-173.

[6] Youxia Bao, Wei Xu, Gang Liu. Chinese Journal of Mechanical Engineering, Vol. 37, No. 2(2001), P105-109. (in Chinese).

[7] Yi Yao, Zan Li, Jianjun Li. Journal of Plasticity Engineering , Vol. 13, No. 6 (2006), pp.29-33. (in Chinese).
