Study on Formation Mechanism of WC in Carburized Layer of Fe-1.57W Binary Alloy

Abstract:

For the better application of the solid carburized processing with simple technology, easy operation, safety and reliability, economic mode, this paper studied the carburized layer of Fe-1.57W binary alloy after solid carburized treatment by OM, SEM, EDS, XRD. Its microstructure was observed and analyzed, and its surface hardness and hardness gradient in the section were measured. At the same time, the formation mechanism and morphology causes of WC were researched and conjectured from the thermodynamics, the crystallography and the valence electron. The results show that: After 930 °C × 8h solid carburized processing and water quenching, the surface hardness of the carburized layer of Fe-1.57W binary alloy is up to HRc59, and its microstructure is composed by M, γ, Fe3C and WC. Fe3C lies in the surface carburized layer. In adjacent layer, there is a layer with large size WC. At 930 °C, WC nucleates on {100} crystal planes in the austenite, and grows along the c-axis direction, under the mutual restriction among the crystal faces of (11 0), ( 2 0) and (2 0) or in the parallel crystal faces of (11 0) and ( 20), and then shows as thin strip, triangle, square, bow-shaped morphology, etc.

• Periodical: Advanced Materials Research (Volumes 154-155)
• Pages: 11-18
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.154-155.11
• Online since: October 2010
• Authors: Jun You Liu, Jie Liu, Xue Yun Gao, Man Li Shi
• Keywords: Fe-W Binary Alloy, Hardness, Microstructure, Solid Carburization, WC

References

[1] A. N. Tarasov and T. P. Kolina: Metalloved. Term. Obrab. Met, 5 (2003), p.32.

[2] T. Babul, T. G. Kucharieva, and A. Nakonechnyi: Metalloved. Term. Obrab. Met., 7 (2004), p.17.

[3] L. Pan: Surface modification heat treatment technology and its application (in Chinese), Beijing: Machinery Industry Press, (2005), p.125.

[4] R. H. Zhang, Y. C. Li, L. B. Song: Harbin Bearing (in Chinese). Vol. 30 ( 2009), p.31.

[5] Buckley Donald H: Amsterdam: Elsevier Scientific . Pub . Co, (1981), p.343.

[6] J. H. Li: Steel metallograph (in Chinese), Shanghai: Shanghai Science and Technology Press, (1981), p.62.

[7] Syouzou Nagasaki, Hirabayashi Makoto, A. S. Liu: Phase diagrams of binary alloy (in Chinese), Beijing: Metallurgy Industry Press, (2004), p.161.

[8] M. C. Sun: Metal mechanical properties (in Chinese), Haerbin: Harbin Institute of Technology Press, (2006), p.29.

[9] T. F. Li: High temperature oxidation and hot corrosion of metal (in Chinese), Beijing: Chemical Industry Press, (2004), p.31.

[10] M. S. Li: High temperature corrosion of metals (in Chinese), Beijing: Metallurgy Industry Press, (2001), p.3.

[11] Y. Hu: Physical chemistry (in Chinese), Beijing: Higher Education Press, (2005), p.94.

[12] Y. J. Liang, Y. C. Che, X. X. Liu: Handbook of inorganic thermodynamic data (in Chinese), Shenyang: Northeastern University Press, (1994), p.83.

[13] Q. L. Yong: The second phase in metallic material (in Chinese), Beijing: Metallurgy Industry Press, (2006), p.91.

[14] W. X. Song: Metallurgy (Second Edition) (in Chinese), Beijing: Metallurgy Industry Press, (2007), p.226.

[15] R. C. Yang, Q. Zhou, L. P. Zheng: Jourlml of Gansu University of Technology (in Chinese), Vol. 3 (2001), p.11.

[16] Y. C. Ye, L. J. He, P. J. Li: Trans. Nonferrous Met. Soc. China, Vol. 20 (2010), p.465.

[17] Y. R. Luo, Q. X. Guo, S. Q. Yu: Chemical bond energies in science today and applications (in Chinese), Hefei: University of Science and Technology of China Press, (2008), p.4.
