Realization of Surface Topography Separation by B Spline Wavelet

Abstract:

With the development of science and technology, the higher and higher surface accuracy of workpiece is required. The characterization of surface topography affect greatly on functional performance of workpiece. In recent years, many researchers have made a large progress on the study of surface topography and presented some related standards. The assessment of parameters of surface roughness, however, has not been researched intensively in the new generation of standards system. This paper proposes a novel roughness separation method based on B spline wavelet to analyze engineering surface. This method improves accuracy of roughness signal separation. The experimental results show that B spline wavelet can extracts accurately the roughness component and experiment results by the proposed method fit with the actual value of the standard sample plate.

• Periodical: Advanced Materials Research (Volumes 154-155)
• Pages: 34-37
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.154-155.34
• Online since: October 2010
• Authors: Mei Fa Huang, Xiong Cheng, Guang Qian, Jiang Tai Huang, Jing Zhang, Hui Jing
• Keywords: B Spline Wavelet, Roughness, Surface Topography, Wavelet Analysis

References

[1] ISO/TS 11562: 1996 (GPS)—Surface Texture: Profile method Metrological Characteristics of Phase Correct Filter.

[2] Y. B. Yuan, X.F. Qiang, J.F. Song, T.V. Vorburger: Precision Engineering vol. 24(2000), pp.62-69.

[3] Q.H. Chen, S.N. Yang, Z. Li: Precision Engineering vol. 23(1999), pp.209-212.

[4] K. Lingadurai, M.S. Shunmugam: Measurement Vol. 39 (2006) pp.575-584.

[5] F.S. Yang. Engineering Analysis and Application of the Wavelet Transform (Science Press, China 1999).
