Load Transfer Analysis Using Indexes U* and U** for Truck Cab Structures in Initial Phase of Frontal Collision

Abstract:

A new index U* which represents load paths in structures was applied to a truck cab under collision. After obtaining the deformed body by a dynamic crash simulation, U* for the extracted deformed body was statically calculated. The distributions of U* were compared with the values of U** obtained in our previous report. The U* and U** distributions show almost the same pattern. However, the absolute value of U* is larger than U** by about 1.6 times. The difference is inevitable because of the difference in their definitions. The concepts of U*sum and its histogram were used to express the effectiveness of the load transfer. Using these expressions, it was shown that the main member of this cab transfers the loading effectively.

• Periodical: Advanced Materials Research (Volumes 156-157)
• Pages: 1129-1140
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.156-157.1129
• Online since: October 2010
• Authors: En Yang Wang, Tetsuo Nohara, Hideaki Ishii, Hiroaki Hoshino, Kunihiro Takahashi
• Keywords: Body, Collision, Load Path, Safety, Structural Analysis, Structure, U*, Vehicle

References

[1] E. Wang, Y. Yoshikuni, Q. Guo, T. Nohara, H. Ishii, H. Hoshino, and K. Takahashi: International Journal of Vehicle Structures and Systems, Vol. 2, No. 2 (2010), p.60.

[2] K. Takahashi and T. Sakurai: Transactions of the Japan Society of Mechanical Engineers, Series A, Vol. 71, No. 708, (2005), p.1097, (in Japanese).

[3] T. Matsunaga, T. Nakada, M. Hanazato, K. Inoue, and K. Takahashi: Transactions of the Japan Society of Mechanical Engineers, Series A, Vol. 75, No. 753 (2009), p.559, (in Japanese).

[4] Y. Okano: Journal of Society of Automotive Engineering of Japan, Vol. 63, No. 7, p.98, (in Japanese).

[5] M. Kamimura, Y. Hatta, S. Ito, Y. Koga, T. Sakurai, and K. Takahashi: Transactions of the Japan Society of Mechanical Engineers, Series A, Vol. 74, No. 737 (2008), p.6, (in Japanese).

DOI: 10.1299/kikaia.74.6

[6] K. Takahashi and T. Sakurai: Transactions of the Japan Society of Mechanical Engineers, Series A, Vol. 71, No. 708 (2005), p.1097, (in Japanese).

[7] H. Hoshino, T. Sakurai, and K. Takahashi: JSAE Review, Vol. 24, No. 2 (2003), p.165.

[8] D.W. Kelly and M.W. Tosh: Engineering Computations, Vol. 17, No. 2 (2000), p.117.

[9] W. Waldman, M. Heller, R. Kaye, and F. Rose: Engineering Computations, Vol. 19, No. 3 (2003), p.305.

[10] H. Harasaki and J.S. Arora: Journal of Computer Methods in Applied Mechanics and Engineering, Vol. 191, No. 3-5 (2001), p.385.

[11] H. Harasaki and J.S. Arora: Journal of Structural and Multidisciplinary Optimization, Vol. 22, No. 1, (2001), p.35.

[12] K. Marhadi and S. Venkataraman: International Journal for Simulation and Multidisciplinary Design Optimization, Vol. 3, No. 3 (2009), p.384.

[13] S. Torikai, Q. Guo, Y. Urushiyama, H. Kobayashi, K. Takahashi: Transactions of Society of Automotive Engineering of Japan, Vol. 41, No. 5, (2010), in press, (in Japanese).
