Rapid Manufacturing and Remanufacturing System Based on Robotic GMAW

Abstract:

This paper describes a novel rapid manufacturing and remanufacturing system based on robotic gas metal arc welding. If worn parts are maintainable, this system play a repairer role; if worn parts are unfit to remain in service, this system play a manufacturer role. This system works in ‘modeling - slicing - stacking’ principle. First, Detecting and building three-dimensional models of damaged zone by structured light. Second, Slicing established three-dimensional model in layers with some thickness. Third, planning robotic tool path to get optimumwelding path and parameters. Finally, executing remanufacturing task with robotic GMAW stacking layer by layer. This system remanufactures parts in human - robot interactive way. Take a half cylinder shell as worn part, experiments are conducted. Results show the mean error of surface smoothness is less than 0.5mm.

• Periodical: Advanced Materials Research (Volumes 156-157)
• Pages: 1626-1629
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.156-157.1626
• Online since: October 2010
• Authors: Zi Qiang Yin, Guang Jun Zhang, Hui Hui Zhao, Lin Wu
• Keywords: Gas Metal Arc Welding (GMAW), Path Plan, Rapid Manufacture (RM), Remanufacture, Slice

References

[1] G.N. Levy, R. Schindel, J.P. Kruth. Rapid manufacturing and rapid tooling with layer manufacturing (LM) technologies, state of the art and future perspectives, Annals of the CIRP. Vol. 52/2, (2003), pp.525-540.

DOI: 10.1016/s0007-8506(07)60206-6

[2] Y.D. Ding, H.B. Lan, J. Hong, D.L. Wu. An integrated manufacyturing system for rapid tooling based on rapid prototyping. Robotics and Computer – Integrated Manufacturing. Vol. 20, (2004), pp.281-288.

DOI: 10.1016/j.rcim.2003.10.010

[3] J.K. Ruan, Y.L. Ke, S.Q. Fan, H.Y. Dong. Research on rapid repairing techniques for auto panel dies. Journal of Materials Processing Technology. Vol. 187-188, (2007), pp.69-72.

DOI: 10.1016/j.jmatprotec.2006.11.152

[4] D. Ma, F. Lin, C.K. Chua. Rapid Prototyping Applications in Medicine, part 1: NURBS – Based Volume Modeling. Advanced Manufacturing Technology. Vol. 18, (2001), pp.103-117.

DOI: 10.1007/s001700170081

[5] W.B. Seaver. Design Considerations for remanufacturability, recyclability and reusability and reusability of user interface modules, Proceedings of IEEE International Symposium on Electronics and the Environment, (IEEE-94), San Francisco, CA, USA, (1994).

DOI: 10.1109/isee.1994.337251

[6] S. Zhu, F.J. Meng, D. Ba. The remanufacturing System based on Robot MAG surfacing. Key Engineering Materials. Vol. 373-374, (2008), pp.400-403.

DOI: 10.4028/www.scientific.net/kem.373-374.400

[7] S.Y. Dong, B.S. Xu, Z.J. Wang, Y.Z. Ma, W.H. Liu. Laser Remanufacturing Technology and its applications. Proc. of SPIE. Vol. 68251N: 1-6, (2007).
