A Novel Slicing Method for Rapid Forming Based on Welding Arc Deposition

Abstract:

Welding arc deposition is a high efficient rapid forming technology which can be used to rapidly form metal functional parts directly. While, Traditional slicing methods in the rapid forming process always produce ‘staircase’ or additional support structure which reduce deposition accuracy and efficiency, bring about the dissipation of materials. Even that it cannot exploit the advantages of welding arc deposition method. This paper proposes a slicing strategy which is suitable for rapid forming based on welding arc deposition. During slicing stage, the CAD model is decomposed into different pieces based on its geometrical feature to make each piece can be deposited in one direction without support structure, and layer thickness is determined according to the height of each sub volume and welding parameter database. A typical part is built with this method. It shows that this method is feasible and high efficient.

• Periodical: Advanced Materials Research (Volumes 156-157)
• Pages: 350-354
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.156-157.350
• Online since: October 2010
• Authors: Sheng Zhu, Jian Liu, Feng Liang Yin, Yuan Yuan Liang
• Keywords: Slicing, Database, Rapid Forming, Welding Arc Deposition

References

[1] W. Cao and Y. Miamoto: Int. J. Adv. Manuf. Technol., 21(2003), p.739.

[2] P. Singh and D. Dutta: J. Computing and Information Science in Engineering Vol. 1(2001), p.129.

[3] Guduri, S., Crawford, R.H. and Beaman, J.J. in: Solid Freeform Fabrication Symposium/Texas(1993), p.291.

[4] Vuyyuru, P. and Kirschman, C. F in: Fifth International Conference on Rapid Prototyping/Dayton, OH(1994), p.229.

[5] X. Chen, C. Wang, X. Ye, Y. Xiao and S. Huang: Int. J. Advanced Manufacturing Technology Vol. 17(2001), p.543.

[6] Tyberg J, Bohn J H : Rapid Prototyping Journal, Vol. 4 (1998), p.118.

[7] W.J. Liu, et al.: Rapid Protyping and Its Application (Mechanical and Industrial Press. Beijing, 2005).
