Research of Technology Parameters on Pipe Axis’ Hot Extrusion Based on Numerical Simulation

Abstract:

A typical parameterized model of pipe axis’ secondary necking in hot extrusion process was built，and the evaluation index of forming effect was proposed. Through using revised constitutive equation in Ansys model combining the method of numerical simulation, several mainly hot extrusion process parameters’ influence on forming effect were analyzed, such as friction, temperature and extrusion speed. The prediction equation of forming effect was worked out by numerical fitting, which provided a feasible way to get the better parameters in hot extrusion process. The experiment shows that the parameters obtained from equations can have a good guide on pipe axis and also other similar workpiece’ s hot extrusion process.

• Periodical: Advanced Materials Research (Volumes 160-162)
• Pages: 1156-1160
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.160-162.1156
• Online since: November 2010
• Authors: Kun Chen, Pei Chen, Quan Guo Luo, Zhao Tun Liu
• Keywords: Hot Extrusion, Numerical Simulation, Pipe Axis, Technology Parameter

References

[1] K. Chen，B. Zhang D.F. Chen. Journal of Computational Information Systems，v3，n2．May 2007. 569-575.

[2] L.C. Yang, B. Liu, M.H. Fan, Y.S. Jiao. CHINA MECHANICAL ENGINEERING(2007).

[3] J. Zhou, X.P. Li. CHINA MECHANICAL ENGINEERING(2006).

[4] X.H. Yang, J.K. Zhu, M.F. Yin, X.N. Guo.   Machinery Design & Manufacture(2003).

[5] Z.C. Huang, J.Q. Zhan, W. Chen.   Machinery Design & Manufacture(2007).

[6] K. Siegert, M. Haussermann, B. Losch. Journal of Materials Processing Technology, 98 (2) : 251-258(2000).

[7] H. Andrej, L. Matjaz, M. Borut. InternationalJournal of Heat and Mass Transfer. 49 : 1027-1038(2006).

[8] N. MERAH, A. AL-ZAYER, A. SHUAIB. International Journal of Pressure Vessels and Piping, 80(12) : 879～885 (2003).

DOI: 10.1016/j.ijpvp.2003.08.007
