Research on Hot Forging Process of C-Grade Steel Train Wheel by FEM

Abstract:

C-grade steel has been widely used for parts of train wheel, train hook and other main parts with its predominant performance. That was mostly produced under high temperature and plastic deformation. In this paper, lots of experiments on the thermo-mechanical simulator Gleeble are operated, and the strain-stress curves under different deforming conditions are obtained. By the analysis of flow stresses under different conditions, the relationship among flow stress, temperature and strain rate as Sellers-Tegart equation is found, and the math model of C-grade steel at high temperature is established. The FEM code DEFORM has been used to simulate the forging process of train wheels. The numerical simulation results show that the first-stage forging parameters have quite important influence on the material distribution and the forge figuration of train wheel. It is necessary to determine the parameters in the pre-forming process reasonably. While, the influencing factors on the forming load are analyzed. The research shows that the heat parameters and the forging speed have influence on the forming load. Lower value of heat transfer coefficient and environment temperature, and lower speed at the ending stage could reduce the forming load significantly in the forging process of train wheels.

You might also be interested in these eBooks

Materials Science and Engineering Applications

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 160-162)

Pages:

492-497

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.160-162.492

Citation:

Cite this paper

Online since:

November 2010

Authors:

Yan Ju Wang, Gang Fang

Keywords:

C-Grade Steel, Finite Element Model (FEM), Flow Stress, Forging, Pre-Forming, Train-Wheel

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Hou peiyun, Wang Qundi, Li Shulin, etc. Application of numerical simulation technology in the hot forming prosess design of train wheel. China metal forming equipment & manufacturing technology. 2009(3)77-81.

Google Scholar

[2] Xu Zhangze, Li Xiang, An Tao, etc. FEM simulation of pre-forging process for railway wheel. Hot working technology, 2004(4): 28-29.

Google Scholar

[3] Plastic deformation of crystal at high temperature. Trans. by Guan Delin. Dalian University of Technology Press. (1989).

Google Scholar

[4] Wang Zhicheng, Wang Zutang, Hu Zhong. Numerical simulation of optimal forming procedure of railroad wheels. Journal of Plasticity Engineering. 1995(4): 3-11.

Google Scholar

[5] K Davey, B C Miler, M J Ward. Efficient strategies for the simulation of railway wheel forming. Journal of Material Processing Technology, 2001: 389-396.

DOI: 10.1016/s0924-0136(01)00985-2

Google Scholar
