Numerical Investigation on Block Shear of Coped Beams with a Welded End Connection

Abstract:

A numerical investigation on the block shear failure behavior of coped beams with double welded clip angle connection was conducted. Parametric study was conducted based on the validated finite element model. The parameters included the web block aspect ratio and the connection rotational stiffness. Based on the mechanical model of double angle connection, the pitch and the beam element length-to-angle thickness (L/t) ratio of the outstanding leg were selected as two importance parameters to consider the effect of the connection rotational stiffness. The results of parametric study show that the connection rotational stiffness has a great influence on the block shear capacity of coped beams with double welded clip angle connection. This is contributed to the fact that for the connections with a smaller connection rotational stiffness, the shear stresses of the shear area were much less than those of the connections with a larger connection rotational stiffness.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 274-278
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.274
• Online since: December 2010
• Authors: Wei Wei Sun, Feng Wei
• Keywords: Block Shear, Coped Beam, Finite Element Analysis (FEA), Parametric Study, Welded Connection

References

[1] P.C. Birkemoe , and M.I. Gilmor. AISC, 15(4), (1978), p.109.

[2] J.A. Yura , P.C. Birkemoe, and J.M. Ricles. Journal of the Structural Division, ASCE, 108(ST2), (1982), p.311.

[3] J.M. Ricles and J.A. Yura. Journal of Structural Engineering, ASCE, 109(ST12), (1983), p.126.

[4] A. Aalberg and P.K. Larsen. Strength and ductility of bolted connections in normal and high strength steels. In: Proceedings of the seventh international symposium on structural failure and plasticity (2000).

DOI: 10.1016/b978-008043875-7/50208-2

[5] G.L. Kulak and G.Y. Grondin. Block shear failure in steel members – a review of design practice. In: Leon RT, and Easterling WS, editors. Proceedings of fourth international workshop on connections in steel structures IV: Steel connections in the new millennium, Chicago (Ill): AISC, (2000).

[6] C.R. Franchuk, R.G. Driver and G.Y. Grondin. Canadian Journal of Civil Engineering, 30(5), (2003), p.871.

[7] C. Topkaya . Journal of Constructional Steel Research, 60(11), (2004), p.1615.

[8] M.C.H. Yam, Y.C. Zhong, A.C.C. Lam and V.P. Iu. Journal of Constructional Steel Research, 63(1), (2007), p.96.

[9] M.C.H. Yam, Y.C. Zhong, A.C.C. Lam and V.P. Iu. Journal of Constructional Steel Research, 63(1), (2007), p.116.

[10] F. Wei, M.C.H. Yam, K.F. Chung and G.Y. Grondin. Journal of Constructional Steel Research, (2010), in press.

[11] ABAQUS/Standard User's Manual Version 6. 6. Hibbitt, Karlsson & Sorensen, Inc (2006).

[12] J.J.R. Cheng and G.L. Kulak. Engineering Journal, (2000), p.133.

[13] M. De Stefano and A. Astaneh. Journal of Constructional Steel Research, Vol. 20, (1991), p.161.

[14] M. De Stefano, A. De Luca and A. Astaneh-Asl. Journal of Structural Engineering. 120(1), (1994), p.212.
