Sensitivity Analysis of Continuous Web Plate Joint of Steel Beam to CFST Column Based on Correlation

Abstract:

This paper deals with probabilistic sensitivity analysis for a semi-rigid joint of continuous web plate based on correlations analysis. Firstly, a numerical study was carried out by the software package ANSYS, the finite element analysis was validated compared with experimental results. Secondly, parameters sensitivity analysis was carried on by applying ANSYS Probabilistic Design Analysis. Considering the correlations in primary parameters, all random parameters are varied at the same time based on Monte Carlo simulation. An especial expression between geometric parameters and moment-rotation was discussed. Thirdly, the moment-rotation model of the joint was attained. The composite constant of the moment-rotation model is determined by partial derivative of any parameter from the model. It is concluded that the parameters of the model have notable physical meaning and the proposed model should be accurate and acceptable.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 264-267
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.264
• Online since: December 2010
• Authors: Jian Rong Pan, Zhan Wang, Cheng Su
• Keywords: Continuous Web Plate, Correlation Analysis, Sensitivity Analysis

References

[1] J.R. Pan. Analytical method on semi-rigid joint of framework based on correlations, PhD dissertation. Shantou University In Chinese (2009).

[2] Z. Wang, J.X. Yuan, J.R. Pan, J. Chen. Advanced Steel Construction, Vol. 2(4)(2006), pp.389-399.

[3] W.F. Chen, E.M. Lui. Stability Design of Steel Frames (CRC press, In Chinese 1991).

[4] Eurocode 3. Design of Steel Structures–Part 1-8：Design of Joints. prEN 1993-1-8. European Committee for Standardisation (CEN) (2003).

[5] S.T. Zhong. The Concrete-Filled Steel Tubular Structures (third edition)(Tsinghua University Press, In Chinese 2004).

[6] G. Cheng, Y. Gu, Y. Zhou (1989). Finite Elements in Analysis and Design, Vol. 6 (1989), pp.113-128.
