Elasto-Plasticity Solution on Bearing Characteristic of Cast-in-Place Concrete Pipe Pile with Large Diameter in Layered Soil under Lateral Load

Abstract:

Aimed at problems lying in the exiting methods for calculation of laterally loaded piles installed in layered soils, the elasto-plasticity solution of cast-in-place concrete pipe pile with large diameter (PCC pile) in layered soil under lateral load based two-parameter foundation model and unity limiting force profile, deduced the finite difference solution based unity limiting force profile(LFP), established the calculation program of the displacement and internal force of pile. It was shown that the calculated pile moment and pile displacement coincided very well by computation and comparison of model test and FEM, verified the method’s correction. Meanwhile, the method was more precise and efficient than the existing conversion methods of subgrade modulus. Therefore, it could be useful for the design and analysis of PCC pile under lateral load.

• Periodical: Advanced Materials Research (Volumes 168-170)
• Pages: 2321-2328
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.168-170.2321
• Online since: December 2010
• Authors: Jian Wei Zhang, Han Long Liu, Gui Yang
• Keywords: Cast-in-Place Concrete Pipe Pile with Large Diameter (PCC Pile), Finite Difference, Lateral Load, Layered Soil, Unity LFP

References

[1] Li-an Han et. al. Calculation of pile under lateral load. Changsha, China, Central South University press(2004), China.

[2] Jinli Liu. Design and calculation of pile foundation. Beijing, China, China Architectured and Building Press(1990), China.

[3] B., McClelland and J. A. Focht Soil modulus of laterally loaded piles., Transactions of the American Society of Civil Engineers, 123: 1049-1063. (1958).

DOI: 10.1061/taceat.0007599

[4] H. Matlock Correlation for design of laterally loaded piles in soft clay., Proc 2nd Offshore Technology Conference, (1): 577-594. (1970).

DOI: 10.4043/1204-ms

[5] Reese L. C., Cox W. R., Koop F. D. (1974). Analysis of laterally loaded piles in sand., Proc 2nd Offshore Technology Conference, Paper OTC 2080, 473-483.

DOI: 10.4043/2080-ms

[6] JGJ 94-2008 Technical code of building pile foundations. (2008).

[7] Ashour, M. A, Morris, G., & Pilling,P. (1998). Lateral loading of a pile in layered soil using the strain wedge model., Journal of Geotechnical and Geoenvironmental Engineering, American Society of Civil Engineers, 124(4): 303-315.

DOI: 10.1061/(asce)1090-0241(1998)124:4(303)

[8] Yang, C. C., & Lin, S. S., Juang, C. H., & Lee, W. F. (2002) . Analysis of laterally loaded piles in two-layered elastic medium., Deep Fdns. American Society of Civil Engineers, GSP, 116: 80-93.

DOI: 10.1061/40601(256)7

[9] Sun, K. M. (1994). Laterally loaded piles in elastic media., J Geotech Engng Div, ASCE, 120(8): 1324-1344.

DOI: 10.1061/(asce)0733-9410(1994)120:8(1324)

[10] Zhao M. H., Li W. Z., Shan Y. M. (2008). Behavior analysis of piles in layered clays under eccentric and inclined loads by improved finite pole element method., Engineering Mechanics, 25(5): 79-84.

[11] Zihang Dai, Linjing Chen (2007). Two numerical solutions of laterally loaded piles installed in muti-layered soils by m method., Chinese Journal of Geotechnical Engineering, 29(5): 690-696.

[12] Hanlong Liu, Kang Fei, Xiaohui Ma (2003a). Cast-in-situ concrete thin-wall pipe pile with vibrated and steel tube mould technology and its application (I): development and design., Rock and Soil Mechanics, 24(2): 164-168.

[13] Hanlong Liu, Xiaoyuan Hao, Kang Fei(2003b). Cast-in-situ concrete thin-wall pipe pile with vibrated and steel tube mould technology and its application (): application and in-situ test., Rock and Soil Mechanics, 24(3): 372-375.

[14] Hanlong Liu, Jianwei Zhang, Jie Peng (2009). Full-scale model test on behavior of cast-in-place concrete pipe pile with large diameter under lateral loads., Chinese Journal of Geotechnical Engineering, 31(2): 161-165.

[15] Jianwei Zhang, Hanlong Liu (2010). Numerical solution of laterally loaded cast-in-place concrete large concrete large diameter pipe pile installed in multi-layered soil., Rock and Soil Mechanics, 31(5): 1638-1644.
