Study on the Vibration of a Paper-Transferring Mechanism

Abstract:

To improve the stability of a Paper-Transferring Mechanism (PTM), a profound understanding must be made on its vibration characteristics, on which based, a modified design was made. Through kinetic and dynamic analysis of the PTM, the natural frequencies were obtained based on the vibration signal detection and noise signal analysis. To reduce the vibration response of the PTM, first is to reduce its maximum acceleration and reduce the quality of moving parts and improve its quality distribution, then structural modification to the wallboards and pull beams of the platform should be made to render its inherent frequencies from its working frequencies.

• Periodical: Advanced Materials Research (Volume 174)
• Pages: 311-314
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.174.311
• Online since: December 2010
• Authors: Ji Fei Cai, Yuan Huang, Xin Zhu Wang
• Keywords: Paper-Transferring Mechanism, Stability Vibration

References

[1] Wang Yiming, Cai Jifei: Chinese journal of mechanical engineering Vol. 18 (2007), p.1255.

[2] Yang Jiahua, Guan Hua: Journal of Beijing University of Technology Vol. 30 (2004), p.35.

[3] Yang Jiahua, Guan Hua: Journal of Beijing University of technology Vol. 32 (2006), p.489.

[4] Zhang Xiaoling, Cai Jifei: Inverse design to the motion law of gripper mechanism of offset press, Vol33, no11, 1126-1130 (2007).

[5] Sun Tianwen, CuiZiwei: Precision machinery and automation (2008).
