Analysis for TCSC in Single Phase Power System Simulation

Abstract:

This paper carries on the stable state simulation and transition condition simulation for the single phase power systems, which are without TCSC and with TCSC systems. Both without TCSC and with TCSC circuits in the single-phase power system, have been carried out a detailed steady state and transition condition simulation, and studied the influence for TCSC that on power system load voltage and load power. In addition, applies the TCSC conventional PID impedance control mode, with TCSC fuzzy PID impedance control in the electrical power system, contrasts their function that display in the electrical power system operation, and demonstrate the two controllers’ advantage and disadvantage. In the stable state simulation, establishes the systems operation separately in the two kind of situations that rated load and overload, observes the respective load voltage profile, and carries on the comparison with other, in order to study the function for TCSC that work s in the single phase power system normal operation time . In the transition condition simulation, establishment short trouble, views the system transition condition’s load voltage, makes its profile the comparison, and studies TCSC in the single phase power system transition condition function. At the same time, considered the difference for TCSC impedance control modes, as well each as the influence which produces to the TCSC performance characteristic, makes the TCSC conventional PID impedance control mode and TCSC fuzzy PID impedance control mode to apply in the single phase power system separately, and carries on the two's simulation profile in detail contrastive analysis . The simulation result indicated that TCSC has the tidal current control and the damping line power vibration, enhances the electrical power system transition condition stably many kinds of functions, in the stable state condition, TCSC can increase system's transportation power, and reduce the electric transmission loss; under the transition condition, TCSC can suppress the system power oscillation and enhance the system stability.

• Periodical: Advanced Materials Research (Volumes 179-180)
• Pages: 20-27
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.179-180.20
• Online since: January 2011
• Authors: Wen Jin Dai, Xiang Jie Chen
• Keywords: Conventional PID Impedance Control, Fuzzy PID Impedance Control, Single Phase Power System, Steady State, Thyristor Controlled Series Capacitor (TCSC), Transient Simulation

References

[1] Li Kejun. TCSC Thyristor Controlled Series complement dynamic simulation and control strategy, Shandong University, (2005).

[2] Fu Minxiu . TCSC physical model and simulation results. Master thesis, North China Electric Power University (2000).

[3] Ge Jun, Tong Luyuan, Geng Juncheng. TCSC based on capacitor voltage under the transient characteristics for synchronous mathematical description, Chinese Society for Electrical Engineering, (2001).

DOI: 10.1109/icpst.2002.1067780

[4] He Ruiwen, Cai ZeXiang. Combined with harmonic characteristics for TCSC Dynamic Phasor Modeling and Characterization of. Chinese Society for Electrical Engineering, (2005).

[5] Zhang Huiyuan, Jiang Jianguo, Feng Yu. TCSC dynamic modeling and digital simulation. Chinese Society for Electrical Engineering, (2003).

[6] R. Mohan Mathur, Rajiv K. Varma. Thyristor-based FACTS control devices. Machinery Industry Press, (2005).

[7] Geng Juncheng, Ge Jun, Tong Luyuan. Based on TCSC line current synchronization transient characteristics analysis. Power Systems, ( 2001).

DOI: 10.1109/icpst.2002.1067780

[8] Wang XueJun, Wen JinYu, Cheng Shijie. Based on synergetic control theory TCSC controller design. Relay.

[9] Zhang Yankui, Zhang Yan, Lu Guoliang. Thyristor controlled series compensation capacitor control angle model and the static voltage stability in the application, Chinese Society for Electrical Engineering, (2005).

[10] Zheng Xu, Pei Zhihong, Sun Haishun. TCSC dynamic model and the impedance characteristics for Device. Electric Power Automation Equipment, （2005）.

[11] Cheng Xu. TCSC dynamic physical system development and characteristics. Huazhong University of Science.

[12] Xu Zheng. TCSC steady-state properties analysis. Power electronics technology, （1998）.

[13] Li Anfu,. Based on Matlab dynamic simulation for power system. Electric Power Automation Equipment, (2005).

[14] Wang Sanwu, Dong Jinfa. Based on Matlab fuzzy self-tuning PID controller design and simulation. Electrical Engineering Technology, (2006).
