Review on Modeling Control System of Earth Pressure Balance Shield Machine

Abstract:

Analysis and design cannot be solved until a proper model of hydraulic control system of earth pressure balance shield machine is built. There are two kinds of modeling methods in common use. (1) Dynamic mathematical modeling. Two models, transfer function and state space, are mainly included. For linear system, the two methods can be provided with a fairly complete theoretical framework. However, if the system is in the complicated working environment or it is non-linear, the modeling process needs a mass of mathematical verification. This has become a limitation for application of these methods; (2) Graphical Modeling. It is more direct for the complex hydraulic control system of earth pressure balance shield machine. First, the main components are separately modeled. Then connect them according to the flow direction of signal. Some special software, such as AMESim, can be used to simplify the simulation process.

• Periodical: Advanced Materials Research (Volumes 181-182)
• Pages: 389-394
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.181-182.389
• Online since: January 2011
• Authors: Hua Peng Li, Dong Wang, Jian Hui Xi, Yi Bo Li
• Keywords: AMEsim, Hydraulic System, Modeling, Shield Machine

References

[1] Information on http: /web. ukonline. co. uk/b. gardner/brunel/tunnel. html.

[2] Russell L: Ports and Dredging, (1996)No. 146, p.15.

[3] Dongliang Liu: Journal of Railway Engineering Society, (2005) No. 2, p.51.

[4] Jianjiang Gu: Underground Engineering and Tunnels, (2002) No. 4, p.54.

[5] Merritt and Mair R J: Geotechnique, Vol. 59 (2006) No. 9, p.605.

[6] Meng FANG: Study on shield advance mechanism electro-hydraulic control system (Ph.D., Zhe jiang University, China 2003), p.15.

[7] Hongtao Chen: Study on Modeling and Simulation of Shield Earth Pressure Balance System (Ph.D., Shandong University of Technology, China 2007), p.14.

[8] Dransfield, P: The Design of Hydraulic System (Science Press, China 1987).

[9] Ruikun Yu, Wanli Li, Qicai Zhou and Wen Lu: Construction Mechanization, (2007) No. 2, p.43.

[10] Chengtong Sun and Hu Han: Coal Mine Machinery, (2008) No. 3, p.52.

[11] Jiasheng Qin and Shanlan You: Machinery and Equipment, (2004) No. 12, p.6.

[12] Jin Li and Weihua Deng: Command Control & Simulation, Vol. 26 (2004) No. 5, p.61.

[13] Honglang Chen and Huacong Li: Fluid Power Transmission & Control, (2006) No. 1, p.14.

[14] Yang Yang, Guofang Gung , Guoliang Hu and Huayong Yang: Machine Tool & Hydraulics, (2006) No. 6, p.119.

[15] Qianwe Zhuang：Integration Technology and Application of Electro-Hydraulic Control System for Earth-Pressure-Balanced Shield (Ph.D., Zhe jiang University, China 2005). P. 24.

[16] Jiuqiang Zheng: Research on Hydraulic Drive System for Cutter Head of Shield Tunnel Boring Machine (Ph.D., Zhe jiang University, China 2005). P. 40.

[17] Youguan Yu: Research on Thrust Electro-Hydraulic Control System for Shield Tunnel Boring Machine (Ph.D., Zhe jiang University, China 2005). P. 51.

[18] Imagine company: AMESim user manual, Version4. 0, France: Imagine S.A., 2002.
