A Research on the Control System of Wind Power Grid-Connected Inverter

Abstract:

PWM inverter, as the main part of wind power grid-connected system, directly determines the quality of the power sent finally to grid. It has become the focus of research to develop a high-performance inverter control system. Based on the analysis and establishment of the mathematical model of the grid inverter system, the vector control strategy based on the voltage directional technique is analyzed in this paper. It consists of two closed loops. The fluctuation of direct voltage is suppressed due to the existence of voltage outer loop. Current inner loop realizes the independent control over meritorious electric current and reactive current through the feedforward of grid voltage and the decoupling of grid-connected current, which makes the inverter power factor close to 1.

• Periodical: Advanced Materials Research (Volumes 181-182)
• Pages: 551-556
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.181-182.551
• Online since: January 2011
• Authors: Jian Guo, Li Gang Song, Yong Yang
• Keywords: Grid-Connected Inverter, Power Factor, Vector Control (VC)

References

[1] X.M. Wang: The DSP Control of Motor: the Application of DSP of TI Company (Beijing Univesity of Aeronautics &Astronautics Press, China 2009).

[2] C.W. Zhang and X. Zhang: PWM Converter and Control (Mechanical Industry Press, China 2003).

[3] Q. Zeng, L. Chang and P. Song, in: SVPWM-based Current Controller with Grid Harmonic Compensation for Three-phase Grid-connected VSI, 35th Annual IEEE Electronics Specialists Conference (2004).

DOI: 10.1109/pesc.2004.1355221

[4] Q.X. Huang. Study on the DSP Control System of the Grid-connected Inverter for Wind Energy Conversion System. Master's Thesis of Beijing Jiaotong University, Beijing, China (2007).
