Dynamic Analysis of Cutter Head System in Tunnel Boring Machine

Abstract:

To obtain the reasonable layout and structure shapes of the various kinds of cutters in tunnel boring machine (TBM), the kinematic/dynamic of cutter head system was analyzed by using virtual prototype and finite element method (FEM). The velocity and force curves were got from different positions of cutters and the mode vibration of scrapers and cutter hobs were obtained to analyze their structural performances next stage. It is shown that these results can provide references for dynamic optimization design of tunnel boring machine. Therefore, it is necessary to implement kinematic/dynamic analysis and mode analysis before manufacture of production.

• Periodical: Advanced Materials Research (Volume 186)
• Pages: 51-55
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.186.51
• Online since: January 2011
• Authors: Li Da Zhu, Peng Cheng Su, Gang Li, Wan Shan Wang
• Keywords: Cutter Head System, Finite Element Model (FEM), Kinematic/Dynamic Analysis, Mode Analysis, Tunnel Boring Machine, Virtual Prototype

References

[1] Jun-Woo Cho, Seokwon Jeon, Sang-Hwa Yu. Optimum spacing of TBM disc cutters: A numerical simulation using the three-dimensional dynamic fracturing method [J], Tunneling and Underground Space Technology, 25(2010): 230-244.

DOI: 10.1016/j.tust.2009.11.007

[2] Su Pengcheng, Wang Wan-shan, Huo Jun-zhou, Optimal Layout Design of Cutters on Tunnel boring Machine[J], Journal of Northeastern University (Natural Science), 2010(6), 877-881 (In Chinese).

[3] Q.M. Gong, J. Zhao. Influence of rock brittleness on TBM penetration rate in Singapore granite[J], Tunneling and Underground Space Technology, 22(2007): 317-324.

DOI: 10.1016/j.tust.2006.07.004

[4] Qiu-Ming Gong, Jian Zhao, Yu-Yong Jiao. Numerical modeling of the effects of joint orientation on rock fragmentation by TBM cutters [J], Tunneling and Underground Space Technology, 20(2005), 183-191.

DOI: 10.1016/j.tust.2004.08.006

[5] Q.M. Gong, Y.Y. Jiao, J. Zhao, Numerical modeling of the effects of joint spacing on rock fragmentation by TBM cutters[J]. Tunneling and Underground Space Technology, 21(2006): 46-55.

DOI: 10.1016/j.tust.2005.06.004

[6] H.Y. Liu, S Q. Kou, P. A. Lindqvist, C.A. Tang, Numerical simulation of the rock fragmentation process induced by indenters[J], International Journal of Rock Mechanics & Mining Sciences, 39(2002)491-505.

DOI: 10.1016/s1365-1609(02)00043-6

[7] Tan Qing, Zhang kui, Zhou zilong, Numerical simulation and experimental observation of rock cracks under action of spherical tooth hob cutter[J], Chinese Journal of Rock Mechanics and Engineering, 2010(1): 163-169. (In Chinese).

[8] Liu Zhijie, Teng Hongfei, Shi yanjun, Cutter head design key issues of a full face rock tunnel boring Machine[J], Chinese mechanical engineering, 2008(8), 1980-1985. (In Chinese).
