The Comparison with Numerical Simulation Results of Steam-Water Flow Field and Experimental Data for Car Exhaust Pipe

Abstract:

In this paper, the physical model for flow field of exhaust pipe has been established on the condition of a liquid-gas exhaust pipe from cars using ethanol gasoline. The numerical simulation results for internal flow field of car exhaust pipe are compared with the experimental data. It is showed that the outside free vortex tangential velocity and axial velocity of single-phase flow field have been simulated better. It is indicated in the simulation of separation process of steam-water two-phase: The relative error, comparing the relationship between flow and separation efficiency with measured of that is less than 7%, and the same to 15%, comparing the relationship between flow and separation ratio with measured of that. Thereby, it is confirmed correctly for the mathematical model founded for numerical calculation and the algorithm selected.

• Periodical: Advanced Materials Research (Volume 187)
• Pages: 570-574
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.187.570
• Online since: February 2011
• Authors: Qing Guo Liu, Yan Ma, Chun Mei Yang
• Keywords: Exhaust Pipe, Experimental Data, Numerical Simulation, Steam-Water Flow Field

References

[1] WangGuiZhi, ZhaoChangLu. The research progress of gasoline engine working process numerical simulation [J]. Vehicles and power operation, 2004, (02).

[2] HanZhanZong, ZhaoFuTang, LiuYaoFeng. The gas flow of engine inlet numerical simulation [J]. Vehicles and power operation, 2001, (02).

[3] SuoWenChao, HanShu, ZhangJing. CFD technology application in design of internal combustion engine [J]. Vehicles and power operation, 2006, (01).

[4] ShenJianPing. The present research ituation and development of internal combustion engine cylinder flow field numerical simulation[J]. Automotive engine, 1997, (01).

[5] HengPing, LiiuChangYong, SongJun. The research of KIVA fuel spray multidimensional model[J]. Automotive engine, 1994, (03).

[6] HuJunJun, ZhouLongBao, HuangYongCheng, HuangZhen. The working process of cylinder direct injection gasoline engine 3d numerical simulation[J]. Automotive engine, 2003, (03).

[7] WangHaiGang, ChenShi, LiuShi. Air inlet internal combustion engine air inlet and flow field in the cylinder numerical simulation[J]. Engineering thermal physical newspaper, 2002, (03).

[8] LiuShuLiang, LiuWuQuan, LiuDeXin, LiZhiJun. rareness burning characteristics of Variable vortex for the Four-valve engine features study[J]. Engineering thermal newspaper , 2002, (04).
