Experimental Study of Titanium Alloy Micro-Holes by EDM Fuzzy Control System

Abstract:

Aiming at machining deep micro-holes in titanium alloy, an experimental approach for EDM adopted a fuzzy control system was introduced. The fuzzy control system based on statistics of discharge states, that pulse interval and jumping height as control parameters, was self-developed. The suitable parameter for the deep micro-hole EDM process can be handily adjusted and modified in visual MATLAB fuzzy editor. A lot of experiments for titanium alloy micro-hole machining were performed on the EDM machine tool adopting the fuzzy control system. A titanium alloy deep micro-hole with 80μm in diameter and 15 in the ratio of depth-diameter is obtained. The process and results of experiments show that the process stability and efficiency be improved; due to the fuzzy control system and its suitable control parameters are applied.

• Periodical: Advanced Materials Research (Volume 188)
• Pages: 195-198
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.188.195
• Online since: March 2011
• Authors: Yu Kui Wang, X.S. Geng, Zhen Long Wang, D.B. Shan
• Keywords: Deep Micro Hole, Fuzzy Control System, Micro-EDM, TC4 Alloy

References

[1] Z.G. Sun, H.L. Hou, H. LI. Effect of hydrogen treatment on microstructure and room temperature deforming properties of TC4 alloy. The Chinese Journal of Nonferrous Metals, Vol. 18(2008), pp.789-793.

[2] Y.L. Yang, G.J. Zhao, D. Zhang. Improving the surface property of TC4 alloy by laser nit riding and its mechanism. Acta Metall Sin, Vol. 19(2006) , pp.151-156.

DOI: 10.1016/s1006-7191(06)60037-9

[3] Z.L. Wang, G.X. Chi, S.C. Di. Micro ultrasonic EDM of deep-small holes in titanium alloys. Acta Armam Entar Ⅱ, Vol. 21(2001) , pp.346-349.

[4] H.Q. Guo, J.Y. Pei, W.Y. Li. Process study of micro hole in EDM. Aerospace Manufacturing Technologies, Vol. 5(2005) , pp.16-18.

[5] M.P. Jahan, Y.S. Wong and M. Rahman. Journal of Materials Processing Technology, Vol. 209 (2009), pp.1706-1716.
