Spatial Cam Modeling and Analysis on Curvature of Conjugated Surfaces

Abstract:

A novel limited slip differential mechanism for wheeled vehicle is introduced in this paper. A new modeling method for spatial cam mechanism used in the differential is detailed derived. The melding method and the formulas of induced normal curvature for conjugate surfaces of the cam mechanisms is derived on basis of meshing theory of conjugated surfaces and differential geometry theory, and the results provide theoretical foundation for the cam optimization.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 1774-1777
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.1774
• Online since: February 2011
• Authors: Yun Jian Cheng, Hong Jiang, Xiao Chun Wang
• Keywords: Cam Transmission, Conjugate Surface, Induced Curvature, Pressure Angle, Spatial Cam

References

[1] Litivn F L. Gear Geometry and Applied Theory, chapter 2, 7, Shanghai Science and Technology Press. (2008).

[2] Shuren Wang, Gear Meshing Theory, TianJin University Press. (1992).

[3] Litivn F L, Zhang Y, Wang J C. Design and geometry of face-gear drives. 114: 642~676. (1992).

[4] Litivn F L, J C Wang. Appliaction of face-gare drives in helicopter transmission. 116: 672~676. (1994).
